Eaton C0150E6U Control Transformer - CSA UL Listed
Part Number: C0150E6U
Quick Summary
Eaton C0150E6U industrial control transformer provides reliable low-voltage power for control circuits in industrial automation. Design teams frequently contend with compatibility gaps, winding losses, and heat build-up when selecting transformers for mixed 50/60 Hz environments. This unit carries CSA Certified, UL Listed, and cUL Certified markings, along with RoHS compliance, delivering safety, regulatory acceptance, and global compatibility. With a compact footprint, copper windings, and a 150 VA rating, it enables lean panel layouts, improved reliability, and reduced energy waste in automation cabinets. From design through installation, this transformer supports faster procurement, predictable performance, and longer service life for critical control circuits.
Product Information
Extended Description
C0150E6U Eaton: Eaton Type MTE industrial control transformer, pv: 240/416/480/600v, 230/400/460/575v, 220/380/440/550v, 208/500v, taps: none, sv: 99/120/130v, 95/115/125v, 91/110/120v, 85/100/110v, 55°c, 150 va
Product Name
Eaton Type MTE industrial control transformer
Catalog Number
C0150E6U
UPC
786680023798
Product Length/Depth
4.331 in
Product Height
4.016 in
Product Width
4.488 in
Product Weight
8.8 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
RoHS Compliant
Certifications
CSA Certified UL Listed cUL Certified
Catalog Notes
Epoxy encapsulated, Laminations of high quality silicon steel to minimize core losses and optimize performance, 50/60Hz operation, 130°C insulation system standard, Molded-in terminals for maximum durability
Coil material
Copper windings
Design
MTE
Tap size
None
Primary voltage
208/500 V, 220/380/440/550 V, 230/400/460/575 V, 240/416/480/600 V
Temperature rating
55°C
Volt ampere rating
150 VA
Secondary voltage
99/120/130 V, 95/115/125 V, 91/110/120 V, 85/100/110 V
Feature: Wide voltage range enables global deployment. Business Impact: Reduces SKU variety and accelerates commissioning in multinational facilities. Application: Control panels, machine controls, and automation cabinets benefit from unified voltage support and simplified wiring. Feature: Copper windings with epoxy encapsulation. Business Impact: Lower core losses and heat, improving efficiency and extending service life in dense panel layouts. Application: Best for compact switchgear where thermal management is critical. Feature: Molded-in terminals and no taps. Business Impact: Easier installation, fewer wiring faults, and improved vibration resistance. Application: Field-serviceable assemblies in harsh industrial environments. Feature: 55°C rating with 130°C insulation. Business Impact: Reliable operation in warm, enclosed spaces with reduced cooling requirements. Application: Enclosed control panels and motor control centers in hot factory settings. Feature: RoHS compliance and CSA UL cUL certifications. Business Impact: Speedier procurement and regulatory approvals, lowering risk in global supply chains. Application: OEM machinery and panel builders seeking compliant, widely recognized components. Feature: Compact dimensions and 8.8 lb weight. Business Impact: Space-saving installation and easier retrofits in tight enclosures. Application: Panel upgrades and retrofit projects where footprint matters.
Get a Quick Quote for a Eaton C0150E6U
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton C0150E6U?
Enquire Now
FAQs
The C0150E6U supports multiple primary voltages including 208/500 V, 220/380/440/550 V, 230/400/460/575 V, and 240/416/480/600 V, with a 150 VA rating. This versatility enables global deployment and simplifies panel design by reducing the need for multiple transformer SKUs.
Yes, the C0150E6U is RoHS compliant and carries CSA Certified, UL Listed, and cUL Certified markings. These certifications support regulatory compliance, safety assurance, and international acceptance across markets.
The transformer measures 4.331 inches long, 4.488 inches wide, and 4.016 inches high, with an approximate weight of 8.8 pounds. Its compact footprint supports dense panel layouts and easier retrofit in existing enclosures.
Secondary voltages are 99/120/130 V, 95/115/125 V, 91/110/120 V, or 85/100/110 V, with a 150 VA rating. The unit operates at 55°C and uses copper windings with epoxy encapsulation for reliability in demanding environments.
Warranty coverage is one year from installation or eighteen months from shipment, whichever occurs first. Eaton provides datasheets, application notes, and spare parts support to help ensure long-term reliability and service in your control systems.
