Eaton C1500E2AFB Industrial Control Transformer - UL Listed
Part Number: C1500E2AFB
Quick Summary
The Eaton C1500E2AFB Industrial Control Transformer delivers reliable low-voltage power for control panels and automation systems. In many facilities, finding a compact, durable transformer that maintains regulation under varying loads and ambient heat is a persistent pain point. The unit carries CSA Certified, cUL Certified, and UL Listed certifications, reinforcing code compliance across North American installations. RoHS compliance, epoxy encapsulation, and robust copper windings support reliability, while 50/60 Hz operation fits standard plant power. This combination translates to lower lifecycle costs, easier maintenance, and smoother integration with motor starters and PLC logic. Designed for optimum core efficiency and molded-in terminals for durability, it's ready for field installation in control cabinets and harsh environments.
Product Information
Extended Description
C1500E2AFB Eaton: Eaton Type MTE industrial control transformer, pv: 240 x 480v, 230 x 460v, 220 x 440v, taps: none, sv: 120/115/110v, 55°c, 1500 va, cu magnet wire,
Product Name
Eaton Type MTE industrial control transformer
Catalog Number
C1500E2AFB
UPC
786680125621
Product Length/Depth
7.5 in
Product Height
7.7 in
Product Width
7.5 in
Product Weight
35.6 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Compliances
RoHS Compliant
Certifications
CSA Certified cUL Certified UL Listed
Catalog Notes
Epoxy encapsulated, Laminations of high quality silicon steel to minimize core losses and optimize performance, 50/60Hz operation, 130°C insulation system standard, Molded-in terminals for maximum durability
Coil material
Copper windings
Design
MTE
Tap size
None
Primary voltage
220 x 440 V, 230 x 460 V, 240 x 480 V
Temperature rating
55°C
Volt ampere rating
1500 VA
Secondary voltage
120/115/110 V
Modification 1
Factory-mounted two-pole primary fuse block for non-rejection type fuses
Special features
Primary fuse block
Eaton Specification Sheet - C1500E2AFB
Selling Policy 25-000 - Distribution and Control Products and Services
Feature: Epoxy-encapsulated construction with laminated silicon steel minimizes core losses. Business Impact: Improves efficiency and long-term reliability in harsh industrial environments. Application: Ideal for control panels and automation cabinets where heat and vibration are concerns. Feature: Copper windings and a 1500 VA rating. Business Impact: Delivers stable, clean power to PLCs, relays, and motor starters, reducing voltage drop risk. Application: Suitable for machine tools, conveyors, and packaging lines. Feature: Molded-in terminals and factory-mounted two-pole primary fuse block. Business Impact: Eases field wiring, enhances safety, and speeds installation with safer, maintenance-friendly connections. Application: Control cabinets and integration points in harsh factories. Feature: Primary voltages of 220 x 440 V, 230 x 460 V, 240 x 480 V and secondary 120/115/110 V. Business Impact: Flexible compatibility with regional power standards and diverse equipment loads. Application: Global deployments in multi-voltage environments. Feature: RoHS compliant and robust insulation (55°C rating, 130°C insulation system). Business Impact: Supports regulatory compliance and improved temperature resilience, reducing maintenance cycles. Application: Industrial automation, process control, and packaging lines.
Get a Quick Quote for a Eaton C1500E2AFB
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton C1500E2AFB?
Enquire Now
FAQs
The C1500E2AFB supports primary voltages of 220 x 440 V, 230 x 460 V, and 240 x 480 V, with a secondary of 120/115/110 V and a volt-ampere rating of 1500 VA. This combination provides flexible power distribution for mid-size control cabinets and automation circuits across regional grids.
Yes, the transformer is RoHS compliant. It carries CSA Certified, cUL Certified, and UL Listed certifications, ensuring broad regulatory acceptance and safe operation within North American electrical codes.
The unit features a factory-mounted two-pole primary fuse block for non-rejection fuses, which simplifies wiring and improves safety by providing a ready-to-wire primary protection solution. This reduces field modification time and helps maintain system integrity during maintenance or expansion.
Common applications include powering PLCs, relays, and motor starters in control panels, conveyors, machine tools, and HVAC control systems. Its 1500 VA rating and versatile primary voltages make it suitable for mid-size automation cabinets and equipment installations requiring reliable low-voltage output.
With epoxy encapsulation, copper windings, and a 130°C insulation system, the transformer is designed for durability in demanding environments and reduced moisture ingress. Routine inspection of molded-in terminals and fuse block connections, plus adherence to RoHS and certification requirements, supports long-term uptime and lower maintenance costs.
