Eaton CB1634B120480C7 Bolted Pressure Switch - UL Listed
Part Number: CB1634B120480C7
Quick Summary
Eaton CB1634B120480C7 bolted pressure switch enables safe, reliable control in high-current switchgear. Engineers often face downtime, space constraints, and demanding 480V, 1600A duty cycles that challenge reliability. UL Listed safety certification supports compliance in industrial environments, while the 480V three-phase capability and bottom-feed design simplify installation. This solution delivers robust performance, reduced maintenance, and predictable operation for critical power distribution applications, pairing corporate reliability with field-ready practicality for your electrical infrastructure.
Product Information
Extended Description
CB1634B120480C7 Eaton: PringleBPS, 1600A, Bottom, 480V 3P w/N-CT, ArcRed/GF Relay-CT, 2NO/2NC
Product Name
Eaton pringle bolted pressure contact switch
Catalog Number
CB1634B120480C7
UPC
786689773625
Product Length/Depth
16 in
Product Height
28 in
Product Width
24 in
Product Weight
180 lb
Certifications
UL Listed
Feed type
Bottom
Fuse configuration
Bottom feed
Number Of Poles
Three-pole
Number of wires
Three-wire
Amperage Rating
1600A
Voltage rating
480 V
Switching Devices Flex Center
Switching Devices Flex Center
Switching Devices Flex Center
Switching Devices Flex Center
Eaton Specification Sheet - CB1634B120480C7
The CB1634B120480C7 delivers a high-current capability at 1600A with a 480V rating, enabling it to safely interrupt and control power in demanding switchgear. Feature to benefit mapping shows improved efficiency, reduced downtime, and enhanced fault management in heavy-duty panels. Its bottom feed and bottom-feed fuse configuration simplify wiring, enabling cleaner enclosures and easier installation in compact spaces. The three-pole, three-wire configuration with 2NO/2NC contacts provides flexible interlocking and sequencing for motor control centers and distribution boards, while ArcRed/GF Relay-CT improves fault indication and trip accuracy. Designed for PringleBPS architectures, it supports reliable integration with Eaton workflows and maintenance practices. Real-world installers report faster commissioning, fewer wire-management issues, and measurable reductions in preventive maintenance costs when using this model in new or retrofits. Long-term, it contributes to safer workplaces and consistent electrical performance in harsh industrial environments.
