Eaton CB223-20 automotive circuit breaker - ATC Type III
Part Number: CB223-20
Quick Summary
CB223-20 automotive breaker is a protection device for automotive circuits that delivers fast, reliable overcurrent protection in compact modules. Engineers often struggle with nuisance trips, space constraints, and the need to maintain safe, maintainable enclosures in tight spaces. This device employs UL-rated 94V-0 thermoplastic housing and RoHS compliance, with a gold cover for Type I and silver cover for Type II/III, to meet demanding safety and environmental standards. Leveraging ATC Type III footprint, it enables straightforward drop-in protection in Bussmann-series installations, reducing install time and inventory complexity. By combining robust protection with a small footprint, it supports cost-effective design iterations and long-term reliability in automotive control panels and harness assemblies.
Product Information
Extended Description
CB223-20 Eaton: Eaton Bussmann series CB223 automotive circuit breaker, type III ATC footprint, 20A, 28 Vdc, UL-Rated 94V-0 thermoplastic housing with gold metal cover (type I) or silver metal cover (type II and III)
Product Name
Eaton Bussmann series CB223 automotive circuit breaker
Catalog Number
CB223-20
UPC
051712614818
Product Length/Depth
1.5 in
Product Height
0.25 in
Product Width
0.75 in
Product Weight
0.02 lb
Compliances
Contact factory RoHS Compliant
Amperage Rating
20 A
Voltage rating
24 V DC
Quantity
1
Bussmann series 4-foot automotive planogram no.10730
CB223-20~ATC CB TYPE 3 -MANUAL RESET - 20 AMP
CB223-20~ATC CB TYPE 3 -MANUAL RESET - 20 AMP
Bussmann series Fuseology
Eaton Specification Sheet - CB223-20
Feature: ATC Type III footprint enables quick, compatible integration with existing Bussmann-series automotive protection layouts. Business Impact: Reduces retrofit time and minimizes custom mounting hardware, increasing engineering throughput and lowering total installed cost. Application: Ideal for control modules and wiring harness protection where space is at a premium and fast serviceability is required. Feature: 20 A, 24 V DC electrical rating provides targeted protection for low-voltage automotive circuits. Business Impact: Prevents costly electrical faults and component damage, supporting longer system life and reduced warranty exposure. Application: Instrument clusters, ECU power rails, and sensor circuits in 12–24 V automotive systems. Feature: Manual reset capability supports deliberate, controlled restoration after fault events. Business Impact: Helps avoid unintended resets and reduces field service time by simplifying fault management. Application: Safety-critical automotive modules and protection relays where operator intervention may be needed. Feature: UL-rated 94V-0 thermoplastic housing with optional gold or silver covers enhances durability and fault resistance. Business Impact: Improves flame retardancy and environmental robustness in harsh automotive environments. Application: Enclosures exposed to heat and vibration in engine bays or under-hood environments. Feature: RoHS compliant construction aligns with modern regulatory expectations. Business Impact: Reduces compliance risk and simplifies global supply chain management. Application: All regions with RoHS requirements for electronic protection components. Feature: Compact dimensions (1.5 in L × 0.75 in W × 0.25 in H, 0.02 lb) enable space-efficient installations. Business Impact: Saves panel space and supports lightweight, high-density protection strategies. Application: Multi-channel automotive protection modules and densely packed control boxes.
