Eaton CB234-20 Automotive Circuit Breaker - 150 AIC
Part Number: CB234-20
Quick Summary
CB234-20 automotive circuit breaker protects automotive circuits from overcurrent. This compact, plug-in protection device is designed for space-constrained harnesses and tight-panel installations. The model supports SAE J1625 and RoHS compliance, with a low-profile, plug-in design that simplifies integration and serviceability. For program managers and sourcing teams, it offers a reliable, field-replaceable protection solution that reduces downtime and streamlines component sourcing while delivering consistent electrical protection for critical loads.
Product Information
Extended Description
CB234-20 Eaton: Eaton Bussmann series C.B.234 automotive circuit breaker, Low profile, 20A, 150 AIC, Plug In
Product Name
Eaton Bussmann series CB234 automotive circuit breaker
Catalog Number
CB234-20
UPC
051712698511
Product Length/Depth
0.03 m
Product Height
0.01 m
Product Width
0.01 m
Product Weight
0.45 g
Warranty
Not Applicable
Compliances
SAE J1625 RoHS Compliant
Amperage Rating
20 A
Interrupt rating
150 AIC
Packaging Type
Standard
Connection
Plug in
Special features
Low profile
Bussmann series 4-foot automotive planogram no.10730
Bussmann series Fuseology
Eaton Specification Sheet - CB234-20
Feature: 20 A amperage rating with 150 AIC interrupt rating. Business Impact: Delivers reliable overcurrent protection for critical automotive circuits while minimizing fault propagation and potential wiring damage. Application: Suitable for automotive control modules and accessory circuits in compact vehicle harnesses. Feature: Low-profile plug-in design. Business Impact: Frees space in crowded control panels and engine bay enclosures, enabling denser wiring layouts and easier retrofit. Application: Engine compartment protection blocks and compact vehicle ECU housings. Feature: Plug-in connection and standard packaging. Business Impact: Speeds assembly, simplifies field replacement, and reduces maintenance time with a familiar, corrosion-resistant connection. Application: Assembly lines, repair shops, and fleet maintenance bays. Feature: Compliance with SAE J1625 and RoHS. Business Impact: Ensures regulatory alignment and environmental compliance, reducing risk in automotive manufacturing and end-use. Application: Automotive electronics manufacturing, tier-1 supplier assemblies, and legislative audits. Feature: Lightweight form factor (0.45 g) and small dimensions (0.03 m L × 0.01 m W × 0.01 m H). Business Impact: Lowers overall vehicle weight and supports lightweight cable harness strategies, contributing to fuel efficiency and space optimization. Application: Space-constrained panel design and high-density module layouts. Feature: Battery and circuit protection with standard packaging. Business Impact: Improves inventory management and sourcing consistency for automotive protection devices. Application: Dealer networks, distributors, and OEM spares catalogs.
