Eaton CB285P-60 circuit breaker - marine rated
Part Number: CB285P-60
Quick Summary
Eaton CB285P-60 circuit breaker protects 48 Vdc DC power systems on vessels and rugged equipment. Vibration, water exposure, and salty environments routinely degrade standard breakers, causing costly downtime. The unit is RoHS compliant and designed for marine use with waterproof sealing, single-pole operation, and switchable functionality. This combination supports safer, lower-maintenance DC protection and simplifies panel mounting in control enclosures. For engineers and procurement teams, it enables scalable, reliable protection across DC circuits while easing compliance and installation workflows.
Product Information
Extended Description
CB285P-60 Eaton: Eaton Bussmann series C.B.285P marine rated circuit breaker, Switchable, 48 Vdc, 60A, 3 kAIC, Automotive, Type III, High amp, Single-pole, Waterproof
Product Name
Eaton Bussmann series CB285P marine rated circuit breaker
Catalog Number
CB285P-60
UPC
051712741125
Product Length/Depth
1.9 in
Product Height
2.91 in
Product Width
1.77 in
Product Weight
0.175 lb
Compliances
Contact factory RoHS Compliant
Amperage Rating
60 A
Interrupt rating
3 kAIC
Voltage rating
48 Vdc
Material
Waterproof
Number of poles
Single-pole
Packaging Type
Standard
Mounting Method
Panel
Special features
Switchable
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Bussmann series Fuseology
Eaton Specification Sheet - CB285P-60
Feature: 60 A amperage rating with a 3 kAIC interrupt capability | Business Impact: Delivers robust protection for high-current DC feeds, minimizing fault damage and downtime | Application: Battery banks, propulsion circuits in marine and industrial equipment. Feature: 48 Vdc rating with switchable functionality | Business Impact: Provides clear fault isolation and flexible protection modes, reducing maintenance complexity | Application: Panel-mounted DC protection in control cabinets and remotely located distribution panels. Feature: Waterproof, single-pole design | Business Impact: Reliable operation in wet or splash-prone environments, extending service life and reducing replacement costs | Application: Marine instrumentation, offshore equipment, and rugged automotive applications. Feature: Panel mounting with standard packaging | Business Impact: Easy integration into existing enclosures, faster installation, and scalable protection across multiple circuits | Application: Dockside gensets, hoists, and other DC-powered systems needing compact protection. Feature: RoHS compliant | Business Impact: Regulatory compliance reduces procurement risk and enables smoother audits | Application: Any electronics or control systems requiring RoHS assurance in harsh environments.
Get a Quick Quote for a Eaton CB285P-60
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CB285P-60?
Enquire Now
FAQs
CB285P-60 is designed for panel mounting, enabling straightforward integration into control enclosures. Its compact footprint (1.9 in depth, 2.91 in height, 1.77 in width) fits tight spaces, and the standard packaging supports quick installation across multiple circuits in marine or industrial panels.
The device provides a 60 A amperage rating with a 3 kAIC interrupt rating and operates at 48 Vdc. It is a single-pole, switchable marine-rated breaker designed for harsh environments, offering reliable short-circuit protection for DC circuits in demanding applications.
Yes. The CB285P-60 is explicitly marine rated and waterproof, making it well-suited for boats, offshore equipment, and rugged automotive installations where DC protection and reliability are critical in wet or salt-air environments.
Eaton lists RoHS compliance for the CB285P-60. The datasheet does not specify CE or IP ratings; for region-specific or additional certifications, consult Eaton’s factory support to confirm requirements for your application.
The 60 A/3 kAIC rating provides strong fault tolerance, reducing downtime and equipment damage. Its compact, panel-mount design simplifies installations, lowers maintenance labor, and supports scalable protection across DC circuits, translating to longer service intervals and cost savings in marine and industrial fleets.
