Eaton CBC-20HB Automotive Circuit Breaker - 1.5 kAIC
Part Number: CBC-20HB
Quick Summary
CBC-20HB automotive circuit breaker is designed to protect vehicle electrical circuits from faults in demanding automotive environments. Engineers often wrestle with mounting fit and consistent interruption performance in vibration-prone layouts; CBC-20HB addresses these pains with rugged #10-32 TPI stud connections and a proven Type I design. Compliance details vary by region and application, so always verify current approvals with Eaton, as some specs are listed as 'Contact factory.' With a 14 Vdc rating and a 20 A interrupt capacity, this device supports reliable protection in modern DC automotive networks, helping reduce downtime and warranty costs while aligning with Bussmann-series protection strategies.
Product Information
Extended Description
CBC-20HB Eaton: Eaton Bussmann series CBC-HB automotive circuit breaker, 14 Vdc, 20 A, 1.5 kAIC, Type I, 10-32 TPI stud
Product Name
Eaton Bussmann series CBC-HB automotive circuit breaker
Catalog Number
CBC-20HB
UPC
051712595445
Product Length/Depth
13.31 in
Product Height
9.63 in
Product Width
1.94 in
Product Weight
0.34 lb
Compliances
Contact factory
Amperage Rating
20 A
Interrupt rating
1.5 kAIC
Voltage rating
14 Vdc
Connection
#10-32 TPI stud
Bussmann series 4-foot automotive planogram no.10730
Bussmann series full line retail catalog no. 5084
Bussmann series full line retail catalog no. 5084
Bussmann series full line retail catalog no. 5084
Bussmann series Fuseology
Eaton Specification Sheet - CBC-20HB
Feature → Business Impact → Application: 14 Vdc rating combined with a 20 A current capacity ensures fast, predictable interruption of faulted circuits in vehicle electrical systems, reducing the risk of collateral damage and downtime. This translates to improved reliability for battery feeds, alternator circuits, and accessory distributions, supporting OEM performance targets while meeting rugged automotive operating conditions. Feature → Business Impact → Application: The CBC-20HB uses a #10-32 TPI stud connection and a compact 13.31 in length with 9.63 in height, enabling straightforward integration into tight engine compartments and retrofit installations. Benefit: simplified installation under vibration, reduced labor time, and compatibility with Eaton Bussmann-series protection components for scalable vehicle protection. Feature → Business Impact → Application: Type I trip behavior and automotive-grade construction improve durability against temperature swings and mechanical shocks, delivering consistent protection across a wide operating envelope, which lowers service calls and warranty costs. Feature → Business Impact → Application: Compliance data is managed through Eaton’s certification program; verify regional requirements with the factory to ensure alignment with CE/UL expectations where applicable, supporting regulatory compliance and customer acceptance in targeted markets.
