Eaton CBF-30 Automotive Circuit Breaker - Type II
Part Number: CBF-30
Quick Summary
The Eaton CBF-30 automotive circuit breaker protects vehicle electrical circuits from overloads, ensuring reliable operation in harnesses and control modules. Engineers often battle nuisance trips and challenging field maintenance in compact automotive panels, making dependable protection crucial for uptime. Compliances show RoHS compliance; however, there are no listed SIL, CE, or IP ratings in this datasheet—please verify with Eaton for your regulatory needs. In practice, this RoHS-compliant solution fits automotive protection strategies within electrical protection & circuit control portfolios, delivering cost-effective reliability and easier replacement in aftermarket or OEM environments.
Product Information
Extended Description
CBF-30 Eaton: Eaton Bussmann series C.B.F automotive circuit breaker, 30A, Type II
Product Name
Eaton Bussmann series CBF automotive circuit breaker
Catalog Number
CBF-30
UPC
051712139526
Product Length/Depth
14.75 in
Product Height
7.5 in
Product Width
9.25 in
Product Weight
0.34 lb
Compliances
Contact factory RoHS Compliant
Amperage Rating
30 A
Bussmann series 4-foot automotive planogram no.10730
CBF-30~TYPE 2 GLASS FUSE CLIP BREAKER - 30 AMP
CBF-30~TYPE 2 GLASS FUSE CLIP BREAKER - 30 AMP
Bussmann series Fuseology
Eaton Specification Sheet - CBF-30
Feature focused design delivers a robust 30 A rating and a Type II glass fuse clip mechanism, translating into precise circuit protection and streamlined maintenance in automotive applications. The business impact is fewer nuisance trips, reduced vehicle downtime, and easier service in fleet operations, with seamless integration into Bussmann-series protection schemes and standard automotive clip layouts. RoHS compliance reduces regulatory and disposal risk, supporting greener manufacturing and simplifying supply-chain compliance for automotive OEMs and aftermarket installers. The compact footprint (14.75 in L x 9.25 in W x 7.5 in H) and light weight (0.34 lb) enable installation in tight panels without compromising space for other protection devices, while preserving reliability. Compatibility with Type II fuse clips enhances retrofit options and minimizes enclosure redesign for existing vehicles and equipment. Industry practitioners benefit from straightforward replacement in protected automotive circuits, aligning with electrical protection & circuit control programs and reducing total cost of ownership.
Get a Quick Quote for a Eaton CBF-30
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CBF-30?
Enquire Now
FAQs
CBF-30 is a Type II glass fuse clip breaker designed for Bussmann-series automotive protection. To verify compatibility, ensure your panel uses Type II clip mounts and confirm the catalog number matches CBF-30. Refer to the CBF-30 TYPE II clip breaker materials and the planogram/catalog references for confirmation.
The device is rated at 30 A, providing overload protection for automotive circuits such as harnesses and control modules. Use in panels and wiring branches that require reliable protection up to 30 A, while aligning with RoHS-compliant component selections for modern vehicle assemblies.
Yes, the CBF-30 is RoHS compliant, helping meet environmental and regulatory requirements by restricting hazardous substances in the electrical protection device. The provided data does not list further certifications like CE or UL; for those, confirm with Eaton or consult the specification sheet to ensure full regulatory coverage for your market.
The product measures 14.75 inches in length, 9.25 inches in width, and 7.5 inches in height, with a weight of 0.34 lb. Plan panel space accordingly and ensure mounting aligns with standard automotive fuse-clip layouts to avoid clearance issues and facilitate quick replacement or service.
Official resources include the Eaton Specification Sheet for CBF-30, Bussmann-series catalogs, and the 4-foot automotive planogram no. 10730. These materials, plus the YouTube Fuseology overview and other downloadable content, are accessible in the product downloads section to support engineering and procurement workflows.
