Eaton CBP-25BA Automotive Circuit Breaker - Type I, 1.5 kAIC
Part Number: CBP-25BA
Quick Summary
CBP-25BA automotive circuit breaker from Eaton protects critical automotive circuits from faults and overloads. When space is tight or harness routing is complex, engineers need protection that fits without compromising reliability or serviceability. The device is RoHS compliant and supported by Eaton datasheets, with additional approvals available through the factory if your application demands it. With a compact 2 in length, 1.3 in width, and a 1.38 in height, plus a rugged #10-32 TPI stud, it delivers robust protection in crowded electrical bays. This combination of compact footprint and proven performance supports efficient design, easier serviceability, and lower total cost of ownership in automotive and mobile equipment projects.
Product Information
Extended Description
CBP-25BA Eaton: Eaton Bussmann series C.B.P-BA automotive circuit breaker, 14 Vdc, 25A, 1.5 kAIC, Type I, 10-32 TPI stud
Product Name
Eaton Bussmann series CBP-BA automotive circuit breaker
Catalog Number
CBP-25BA
UPC
051712601542
Product Length/Depth
2 in
Product Height
1.38 in
Product Width
1.3 in
Product Weight
0.4 lb
Compliances
Contact factory RoHS Compliant
Amperage Rating
25 A
Interrupt rating
1.5 kAIC
Voltage rating
14 Vdc
Connection
#10-32 TPI stud
Quantity
35
Bussmann series 4-foot automotive planogram no.10730
Bussmann series full line retail catalog no. 5084
Bussmann series full line retail catalog no. 5084
Bussmann series full line retail catalog no. 5084
Bussmann series Fuseology
Eaton Specification Sheet - CBP-25BA
Compact form factor with a 2 in length, 1.3 in width, and 1.38 in height, plus a #10-32 TPI stud connection enables dense packaging and straightforward installation in crowded automotive harnesses. Business impact: space savings, faster assembly, and reduced wiring complexity, improving overall assembly time and reducing labor costs. Application: electrical protection right at the harness entry point in compact vehicle control panels and mobile equipment. 25 A rating at 14 Vdc with 1.5 kAIC interrupt capacity provides reliable protection for moderate automotive loads while limiting nuisance trips during normal operation. This translates to higher system uptime and lower risk of component damage under fault conditions. Application: infotainment, sensor arrays, and power distribution in light vehicles. Type I trip characteristics offer predictable protection behavior under automotive fault scenarios, supporting consistent maintenance planning and easier troubleshooting. Business impact: deterministic response improves diagnostic workflows and reduces warranty claims. RoHS compliant status ensures regulatory alignment across markets; consult the factory for additional certifications if required. Application: global OE programs and aftermarket deployments. Robust connection capability with a #10-32 TPI stud supports vibration resistance and durable terminations in automotive environments. Business impact: fewer connection failures and longer mean time between maintenance actions. Documentation and availability: the CBP-25BA is supported by Eaton catalogs, specification sheets, and planograms, enabling seamless procurement and engineering alignment. Application: design validation and supplier-ready documentation for automotive programs.
