Eaton CBS-20 Automotive Circuit Breaker - RoHS Compliant
Part Number: CBS-20
Quick Summary
The Eaton CBS-20 automotive circuit breaker provides reliable overcurrent protection for automotive electrical circuits. Many designs suffer nuisance trips and wiring faults in harsh vehicle environments. This device is RoHS compliant; for other regulatory approvals, consult the factory. Its compact 4.67 in length, 1.84 in width, and 1.6 in height fits tight automotive enclosures, while a 20 A rating protects circuits without nuisance trips. With Eaton's Bussmann lineage, you benefit from established reliability and easy sourcing. Designed for integration with Bussmann series planograms and automotive harnesses. Its small footprint and lightweight design simplify protection in space-constrained installations. The included catalog and datasheet support fast specification and procurement decisions.
Product Information
Extended Description
CBS-20 Eaton: Eaton Bussmann series C.B.S automotive circuit breaker, 20A
Product Name
Eaton Bussmann series CBS automotive circuit breaker
Catalog Number
CBS-20
UPC
051712139571
Product Length/Depth
4.67 in
Product Height
1.6 in
Product Width
1.84 in
Product Weight
0.18 lb
Compliances
Contact factory RoHS Compliant
Amperage Rating
20 A
Bussmann series 4-foot automotive planogram no.10730
Bussmann series full line retail catalog no. 5084
Bussmann series full line retail catalog no. 5084
Bussmann series full line retail catalog no. 5084
Bussmann series Fuseology
Eaton Specification Sheet - CBS-20
The CBS-20 delivers a 20 A amperage rating for automotive circuits, enabling precise overcurrent protection that guards harnesses and loads from wiring damage. This targeted protection reduces the likelihood of costly automotive electrical failures and unexpected downtime. With a compact footprint of 4.67 in long, 1.84 in wide, and 1.6 in high, the device fits crowded fuse blocks and tight dash panels. Installation becomes quicker and more reliable, as fewer enclosures require oversized protection devices. RoHS compliance supports regulatory alignment and sustainable sourcing, simplifying audits and supplier qualification. It minimizes supply chain risk by standardizing a widely accepted environmental standard across automotive programs. Traceability is streamlined by catalog data and UPC 051712139571, aiding BOM management and field replacements. This level of inventory control accelerates procurement and reduces misorders. Compatibility with Eaton Bussmann series protection products and planograms aids seamless integration into existing protection schemes. The CBS-20 aligns with Bussmann catalogs and common automotive fuse blocks, reducing retraining and enabling fast stock replenishment. Real-world insights show that reliable 20 A protection improves uptime under temperature cycling and vibration, with fewer nuisance trips and simpler warranty support when using a proven Bussmann series option.
