Eaton CCP-1-60CF Fusible Disconnect - 60A/600Vac
Part Number: CCP-1-60CF
Quick Summary
The Eaton CCP-1-60CF fusible disconnect provides reliable circuit isolation in electrical protection and control panels. Engineers and technicians often face downtime and maintenance headaches when isolation devices trip unnecessarily or lack clear indicators. UL 98 listing ensures safe, code-compliant isolation, and RoHS compliance supports modernization and environmental requirements. Its compact footprint and straightforward mounting simplify panel design, while the 60A, 600Vac rating supports robust power control in industrial environments, delivering predictable performance with reduced installation time and lifecycle costs.
Product Information
Extended Description
CCP-1-60CF Eaton: Eaton Bussmann series military fuse, 125V, 25A, Non Indicating, CCP-1-60CF
Product Name
Eaton Bussmann series CCP UL98 fusible disconnect
Catalog Number
CCP-1-60CF
UPC
051712201490
Product Length/Depth
3.65 in
Product Height
3.14 in
Product Width
2.07 in
Product Weight
0.334 lb
Warranty
Not Applicable
Compliances
Not Applicable RoHS Compliant
Certifications
Contact Manufacturer
Amperage Rating
60A
Voltage rating
600 Vac, 125 Vdc
Fuse type
CUBEFuse
Number Of Poles
Single-pole
60A at 600Vac and 125Vdc capability provides robust protection for mid-to-high power circuits in control panels, motor starters, and power distribution cabinets, enabling reliable isolation with a compact footprint. This reduces panel size requirements and simplifies wiring, translating into faster installation and lower upfront costs. The single-pole CUBEFuse design delivers dependable overcurrent protection with straightforward replacement, minimizing downtime during maintenance. Non-indicating operation reduces panel clutter, while external status indicators or control feedback can be added for clear remote monitoring, enabling safer, more efficient operations in assembly lines and manufacturing facilities. The RoHS-compliant construction supports modern environmental standards, aligning with procurement policies for sustainable industrial equipment. Rugged dimensions (3.65 in L x 3.14 in H x 2.07 in W) and a 0.334 lb weight make it suitable for tight electrical enclosures and MCCs, with straightforward compatibility to standard Bussmann/Eaton accessories.
Get a Quick Quote for a Eaton CCP-1-60CF
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CCP-1-60CF?
Enquire Now
FAQs
The CCP-1-60CF is designed for electrical protection and control panels in industrial environments, including motor control centers and power distribution cabinets. Its compact single-pole package fits tight spaces, while its UL98 fuse disconnect provides safe isolation during maintenance and fault conditions. It integrates easily with standard busbar and enclosure configurations for quick deployment.
The device is rated for 60A and supports a voltage range of 600 Vac and 125 Vdc. As a single-pole CUBEFuse-type disconnect, it delivers reliable current interruption for typical industrial loads while meeting common panel-mount requirements. Follow NEC guidelines for wiring and enclosure ratings to ensure compliant installation.
RoHS compliance is indicated in the datasheet, with UL 98 listing suggested by the product description. The datasheet does not specify CE labeling or SIL/IP certifications; however, the unit is designed for RoHS-compliant manufacturing and safe operation within standard industrial power protection schemes.
Non-indicating means there is no built-in visual status indicator on the disconnect itself. For maintenance or fault diagnostics, rely on external indicators or control system feedback. This reduces internal panel clutter and allows easier modding of status monitoring, while preserving the device’s protection performance. Ensure external diagnostics are in place for clear visibility.
By delivering reliable, code-compliant isolation with a compact footprint, it reduces panel size, installation time, and labor costs. The rugged CUBEFuse design and RoHS compliance support long service life in demanding environments, lowering maintenance frequency and total cost of ownership for power distribution and protection systems.
