Eaton CCP2-1-300CF Fusible Disconnect - UL98 Certified
Part Number: CCP2-1-300CF
Quick Summary
The Eaton CCP2-1-300CF fusible disconnect provides safe isolation for high current control panels. Engineers often struggle to achieve reliable interrupting capacity while maintaining quick access during maintenance. This unit carries UL98 listing, supports a 200 kAIC short-circuit rating, and operates at 600 Vac and 125 Vdc, covering diverse industrial needs. Its compact single-pole design, finger-safe body, and lock-on provision simplify installation and ongoing compliance. With a robust footprint in power distribution, machine control, and panel upgrades, it offers predictable performance and lower total cost of ownership through robust protection and easy serviceability.
Product Information
Extended Description
CCP2-1-300CF Eaton: Eaton Bussmann Series Compact Circuit Protector, 600Vac, 125Vdc, 300A, Single-pole, CUBEFuse
Product Name
Eaton Bussmann series CCP UL98 fusible disconnect
Catalog Number
CCP2-1-300CF
UPC
051712690218
Product Length/Depth
10.125 in
Product Height
5.2 in
Product Width
1.72 in
Product Weight
2.917 lb
Warranty
Not Applicable
Compliances
Not Applicable
Amperage Rating
300 A
Short-circuit rating
200 kAIC
Voltage rating
600 Vac, 125 Vdc
Number Of Poles
Single-pole
Special features
Finger Safe, Lock-On provision
The CCP2-1-300CF delivers a 300 A amperage rating, enabling protection of high current circuits without oversized devices. This translates to a lower installed cost and a smaller panel footprint, improving assembly times and reducing wiring complexity in control cabinets. For machine builders and system integrators, this means you can consolidate protection around a single unit rather than multiple devices, increasing reliability and simplifying procurement. With a short-circuit rating of 200 kAIC, the unit withstands severe fault currents common in industrial facilities, reducing nuisance trips and equipment damage during faults and enhancing line availability. Its voltage rating of 600 Vac and 125 Vdc supports mixed AC and DC systems, enabling easier integration in modern power architectures across control panels and motor drives. The single-pole construction reduces depth, making panel layouts simpler while preserving full protection capability. The finger-safe design and lock-on provision improve worker safety during servicing and ensure secure operation during maintenance cycles. Compact dimensions and compatibility with Eaton Bussmann series accessories streamline installation and future upgrades, delivering a lower total cost of ownership for panel builders and end users.
Get a Quick Quote for a Eaton CCP2-1-300CF
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CCP2-1-300CF?
Enquire Now
FAQs
Plan for a single-pole protection device with a footprint that fits tight enclosures. The unit measures 10.125 in in depth, 5.2 in in height, and 1.72 in in width, enabling straightforward mounting in standard electrical panels. Ensure wiring complies with 600 Vac and 125 Vdc ratings and that finger-safe and lock-on features are accessible for safe servicing during maintenance.
A 200 kAIC short-circuit rating indicates high fault current is safely interrupted without device failure. This translates to improved protection of feeders and motors in facilities with high fault currents, reducing the risk of cascading damage and lowering the probability of unscheduled downtime during electrical faults.
Yes. The 300 A amperage rating, UL98 certification, and 600 Vac / 125 Vdc capability make it well suited for industrial machinery, control panels, and DC bus protection. Its compact single-pole design simplifies panel integration, while finger-safe and lock-on features support safe maintenance in busy machine environments.
The CCP2-1-300CF is UL98 listed, indicating compliance with recognized safety standards for fusible disconnects. The 200 kAIC rating provides a generous fault-current margin, and the 600 Vac / 125 Vdc ratings support mixed AC/DC installations. Together, these attributes help meet industrial safety requirements and support safer panel upgrades and maintenance practices.
The unit consolidates protection into a single, rugged disconnect, reducing part count and simplifying procurement. Its finger-safe and lock-on features speed maintenance while enhancing safety. The compact footprint improves enclosure utilization, potentially lowering build costs and downtime during fuse changes, which translates to lower total cost of ownership in ongoing operations.
