Eaton CCP2-2-300CF Fusible Disconnect - UL98
Part Number: CCP2-2-300CF
Quick Summary
Eaton CCP2-2-300CF is a compact UL98 fusible disconnect used for safe isolation in industrial power distribution. Facilities teams often struggle with space constraints, wiring complexity, and maintaining compliant isolation under load. UL 98 listing is the primary certification highlighted for this model, complemented by its finger-safe design and Lock-On provision to support safe maintenance. In addition to protecting circuits up to 600 Vac, 125 Vdc and 300 A, the unit helps reduce panel footprint, streamline procurement, and simplify documentation for ongoing compliance. Engineered to work with the Bussmann series ecosystem, it offers predictable compatibility with common control architectures and aftermarket spares, delivering measurable efficiency and reliability gains in industrial environments.
Product Information
Extended Description
CCP2-2-300CF Eaton: Eaton Bussmann Series Compact Circuit Protector, 600Vac, 125Vdc, 300A, Two-pole, CUBEFuse
Product Name
Eaton Bussmann series CCP UL98 fusible disconnect
Catalog Number
CCP2-2-300CF
UPC
051712690225
Product Length/Depth
10.125 in
Product Height
5.2 in
Product Width
1.72 in
Product Weight
5.834 lb
Warranty
Not Applicable
Compliances
Not Applicable
Amperage Rating
300 A
Short-circuit rating
200 kAIC
Voltage rating
600 Vac, 125 Vdc
Number Of Poles
Two-pole
Special features
Finger Safe, Lock-On provision
Feature: Compact two-pole CCP UL98 fusible disconnect reduces panel footprint and simplifies wiring, enabling faster panel assembly and easier future expansions. Business Impact: Frees space in crowded control panels while maintaining reliable fault protection, reducing enclosure costs and retrofit complexity. Application: Ideal for control panels in motor drives, manufacturing lines, and process equipment where space and safety are priorities. Feature: High short-circuit rating of 200 kAIC provides robust protection against high-energy faults, limiting damage to downstream equipment and downtime. Business Impact: Improves equipment reliability and uptime, lowering maintenance costs and unplanned outages. Application: Suitable for high-demand drives and feeder circuits in heavy industrial environments. Feature: Voltage rating of 600 Vac and 125 Vdc supports mixed-power systems within a single protective device, reducing parts count and inventory complexity. Business Impact: Simplifies procurement and spares planning while ensuring consistent protection across AC and DC sections. Application: Industrial power distribution and motor control centers with mixed supply rails. Feature: Finger Safe and Lock-On provision enhance maintenance safety and operational security, preventing accidental disconnection during service. Business Impact: Safer maintenance routines and fewer inadvertent shutoffs, boosting technician confidence and process stability. Application: Routine maintenance, testing, and safe lockout/tagout scenarios in production lines. Feature: Dimensional and weight specs—10.125 in length, 5.2 in height, 1.72 in width, and about 5.834 lb—facilitate enclosure planning and retrofit fitment. Business Impact: Predictable mounting in standard enclosures reduces installation time and service complexity. Application: Panel upgrades, retrofits, and new builds requiring compact, compatible protection devices.
Get a Quick Quote for a Eaton CCP2-2-300CF
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CCP2-2-300CF?
Enquire Now
FAQs
Install CCP2-2-300CF as a two-pole disconnect within a suitable electrical panel or enclosure. Ensure mounting aligns with standard knockouts, connect conductors to the appropriate lugs, and verify clearances for finger-safe operation. Engage the Lock-On provision after wiring to prevent accidental disconnection during service, and follow lockout/tagout procedures during maintenance. The unit supports common Bussmann series wiring practices and is designed to integrate with typical industrial control architectures.
Key ratings include an amperage of 300 A, a short-circuit rating of 200 kAIC, and voltage ratings of 600 Vac and 125 Vdc. It is a two-pole device designed for protection in AC and DC circuits up to these limits. The product aligns with UL98 fusible disconnect standards, and its compact form factor supports reliable performance in space-constrained installations.
Yes. The 300 A rating, 600 Vac capability, 200 kAIC fault tolerance, and two-pole configuration make it appropriate for motor control circuits and protection in manufacturing environments. It integrates with Bussmann series protection schemes and supports safe isolation during maintenance, helping to minimize motor downtime and protect downstream equipment.
The primary certification highlighted is UL 98 listing for fusible disconnects. The datasheet specifies UL 98 compliance, but CE marking or IP ratings are not indicated in the available data. For projects requiring additional certifications, verify with Eaton or consult the official specification sheet for any region-specific requirements.
Expected benefits include reduced panel footprint due to the compact two-pole design, simplified spare-part inventories from a single protective device, and safer maintenance through finger-safe geometry and Lock-On security. Its high fault tolerance and robust ratings also help minimize downtime from faults and streamline preventative maintenance planning.
