Eaton CCP2-3-300CF UL98 Fusible Disconnect – 600 Vac
Part Number: CCP2-3-300CF
Quick Summary
The Eaton CCP2-3-300CF UL98 fusible disconnect isolates power in industrial equipment and control panels. A common challenge is achieving safe, reliable disconnection without downtime or nuisance trips during maintenance. While explicit SIL, CE, or IP ratings aren’t listed in this model’s spec, the UL98 listing and finger-safe, lock-on features deliver robust protection and ease of use. With a three-pole design rated for 300 A at 600 Vac and 200 kAIC fault tolerance, it supports demanding drives and motor loads. This combination lowers maintenance costs, simplifies panel layout, and provides a clear path to compliant isolation in control enclosures, helping engineering teams deliver safer, more reliable systems.
Product Information
Extended Description
CCP2-3-300CF Eaton: Eaton Bussmann Series Compact Circuit Protector, 600Vac, 125Vdc, 300A, Three pole, CUBEFuse
Product Name
Eaton Bussmann series CCP UL98 fusible disconnect
Catalog Number
CCP2-3-300CF
UPC
051712690232
Product Length/Depth
10.125 in
Product Height
5.2 in
Product Width
1.72 in
Product Weight
8.751 lb
Warranty
Not Applicable
Compliances
Not Applicable
Amperage Rating
300 A
Short-circuit rating
200 kAIC
Voltage rating
600 Vac, 125 Vdc
Number Of Poles
Three pole
Special features
Finger Safe, Lock-On provision
Feature: 300 A continuous current rating at 600 Vac enables handling of heavy motors and feeders without early fuse failure. Business Impact: Reduces thermal stress on upstream components and minimizes nuisance trips, improving line uptime and efficiency. Application: Ideal for motor drives, large feeders, and control panels where reliable isolation and protection are critical.Feature: Short-circuit rating of 200 kAIC delivers high fault tolerance. Business Impact: Engineers can design protection with a generous safety margin, reducing reassessment when layouts change. Application: Suitable for high-energy projects and equipment prone to large inrush or fault currents in manufacturing lines.Feature: Three-pole configuration ensures simultaneous disconnection of all phases. Business Impact: Promotes safer maintenance by preventing partial energization and supports coordinated protection strategies. Application: 3-phase motors, conveyors, and drives in electrical systems requiring synchronized isolation.Feature: Finger Safe construction with Lock-On provision improves maintenance safety. Business Impact: Prevents accidental energization during servicing and facilitates secure, repeatable isolation. Application: Panel-mounted disconnects in control enclosures and switchgear assemblies.Feature: Compact dimensions and weight enable flexible panel integration. Business Impact: Saves enclosure space, simplifies wiring, and reduces installation time. Application: Compact control panels, switchgear assemblies, and limited-space electrical cabinets.
Get a Quick Quote for a Eaton CCP2-3-300CF
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CCP2-3-300CF?
Enquire Now
FAQs
Installers should verify that the three-pole CCP2-3-300CF fits the enclosure footprint (10.125 in long, 5.2 in high, 1.72 in wide) and provide proper three-wire connections to each pole. Use the finger-safe housing and engage the lock-on feature to prevent re-energization during maintenance. Follow Eaton's wiring practices and ensure clearance for safe operation.
The unit is rated for 300 A continuous current, 600 Vac and 125 Vdc, with a short-circuit rating of 200 kAIC. It is a three-pole device designed for three-phase circuits in industrial control scenarios. These ratings support heavy motor loads and high fault conditions, enabling safer isolation in power distribution and drive systems.
Yes. With a robust 300 A rating, 600 Vac capability, and 200 kAIC fault tolerance, the CCP2-3-300CF is well-suited for motor control centers, drives, and other high-energy installations. Its finger-safe design and lock-on feature simplify maintenance, while its compact footprint aids panel integration in space-constrained MCCs.
This model carries UL98 fusible disconnect listing, providing recognized safety certification for isolation devices. The data does not list CE or IP ratings for this variant, so verify project requirements and any regional electrical standards. For most industrial installations, UL-listed CCP disconnects meet essential protection criteria and integrate with standard switchgear.
The lock-on feature and finger-safe housing reduce maintenance risk and re-energization errors, while the high fault rating minimizes nuisance outages during faults. Its compact size streamlines enclosure wiring and reduces panel costs, contributing to faster commissioning and lower lifecycle costs in manufacturing environments.
