Eaton CCP2B-3-30CF Fusible Disconnect - UL98 Certified
Part Number: CCP2B-3-30CF
Quick Summary
The Eaton CCP2B-3-30CF fusible disconnect provides safe, code-compliant circuit protection for industrial feeders. For engineers wrestling with downtime and maintenance hazards, this unit offers quick isolation with a finger-safe design and a secure Lock-On provision. It carries UL98 fusible disconnect recognition and CCC Marked compliance, aligning with global safety and regulatory expectations. With three poles and a sturdy 225 A rating at up to 600 VAC (125 VDC) and a 200 kAIC short-circuit rating, it supports demanding motor and power-distribution applications. Compact, easy-to-install form factors and compatibility with Bussmann-series protection help you optimize panel space while reducing installation time and lifecycle costs.
Product Information
Extended Description
CCP2B-3-30CF Eaton: Eaton Bussmann series CCPB UL98 fusible disconnect, Finger Safe, Lock-On provision, 600 Vac, 125 Vdc, 225A, UL98 fusible disconnect, Three-pole, 200 kA - CCP2B-3-30CF
Product Name
Eaton Bussmann series CCPB UL98 fusible disconnect
Catalog Number
CCP2B-3-30CF
UPC
051712709415
Product Length/Depth
2.7 in
Product Height
3.9 in
Product Width
3 in
Product Weight
3.7 lb
Warranty
Not Applicable
Compliances
CCC Marked
Certifications
Contact Manufacturer
Amperage Rating
225 A
Short-circuit rating
200 kAIC
Voltage rating
600 Vac, 125 Vdc
Number Of Poles
Three-pole
Special features
Finger Safe, Lock-On provision
Finger Safe design and a Lock-On provision improve operator safety and prevent accidental reseating during maintenance. This translates to fewer near-miss incidents and easier lockout-tagout workflows in high-turnover panels. Applications include control panels for conveyors, pumps, and packaging lines where safe isolation is critical. Three-pole disconnection ensures all phases are interrupted simultaneously, reducing arc flash risk and preventing phase-to-phase damage in demanding 3-phase motor circuits. The high 225 A rating with a 200 kAIC short-circuit capacity supports heavy loads and fast fuse clearing, delivering reliable protection for feeders and large motors. Its 600 VAC / 125 VDC voltage capability provides broad compatibility with diverse industrial equipment, while the compact footprint simplifies panel integration. Compliance features, including UL98 compatibility and CCC Marked status, streamline procurement and global installations, and the Lock-On plus Finger Safe features improve installation reliability and maintenance safety. The small 2.7 in depth, 3 in width, and 3.9 in height footprint enables efficient enclosure design and helps reduce overall system cost over the equipment lifecycle.
Get a Quick Quote for a Eaton CCP2B-3-30CF
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CCP2B-3-30CF?
Enquire Now
FAQs
The CCP2B-3-30CF is a three-pole UL98 fusible disconnect designed for industrial panels. It supports 225 A continuous operation with a 600 VAC / 125 VDC rating and features Finger Safe access and a Lock-On provision for safe, compliant maintenance. When integrating, ensure panel space accommodates its 2.7 in depth and 3 in width, and verify it interfaces with standard Bussmann-series protective devices for coordinated protection and predictable fault clearing.
Key ratings include Amperage Rating of 225 A, Short-circuit rating of 200 kAIC, and Voltage Rating of 600 Vac and 125 Vdc. The device is a three-pole protection disconnect, delivering reliable isolation for high-current, three-phase circuits while maintaining safe operation through a finger-safe design and Lock-On feature.
Yes. With three-pole construction, 225 A capacity, and a 200 kAIC short-circuit rating, CCP2B-3-30CF is well-suited for isolating and protecting three-phase motors and feeders in industrial environments. Its UL98 fusible disconnect compatibility and robust voltage ratings support safe startup, shutdown, and service operations without compromising protection or accessibility.
The CCP2B-3-30CF is identified as UL98 fusible disconnect capable and CCC Marked for compliance. Certifications indicate alignment with safety and regional standards. For additional confirmations or any special certification needs, contact the manufacturer to verify current status and any region-specific approvals.
Finger-safe enclosures reduce the risk of accidental contact during servicing, while Lock-On prevents inadvertent reseating, improving operator safety and reducing downtime. The three-pole design minimizes re-assembly errors, and the compact footprint saves panel space, lowering enclosure costs. Over the equipment lifecycle, these features contribute to safer maintenance, faster service, and improved uptime, delivering measurable cost savings in industrial automation environments.
