Eaton CCP2B-3-50CF Fusible Disconnect - UL98
Part Number: CCP2B-3-50CF
Quick Summary
The Eaton CCP2B-3-50CF Fusible Disconnect is a three-pole isolation device designed for reliable protection of industrial motor feeders and power distribution panels. Many facilities struggle with unsafe access and complicated lockout procedures during maintenance; this unit features Finger Safe construction and a Lock-On provision to streamline safe service. With UL98 compliance and CCC Marked certification, it meets critical safety and regulatory requirements for North American and international applications. The compact, rugged design delivers solid fault-current protection while minimizing panel footprint. The combination of 225 A rating at 600 Vac / 125 Vdc and a 200 kAIC short-circuit rating supports demanding environments, helping reduce downtime and improve overall site safety. It integrates smoothly with Bussmann series protection schemes and existing three-pole installations.
Product Information
Extended Description
CCP2B-3-50CF Eaton: Eaton Bussmann series CCPB UL98 fusible disconnect, Finger Safe, Lock-On provision, 600 Vac, 125 Vdc, 225A, UL98 fusible disconnect, Three-pole, 200 kA - CCP2B-3-50CF
Product Name
Eaton Bussmann series CCPB UL98 fusible disconnect
Catalog Number
CCP2B-3-50CF
UPC
051712709477
Product Length/Depth
2.7 in
Product Height
3.9 in
Product Width
3 in
Product Weight
3.7 lb
Warranty
Not Applicable
Compliances
CCC Marked
Amperage Rating
225 A
Short-circuit rating
200 kAIC
Voltage rating
600 Vac, 125 Vdc
Number Of Poles
Three-pole
Special features
Finger Safe, Lock-On provision
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - CCP2B-3-50CF
Feature → Three-pole design supports balanced, three-phase isolation for motor drives and power distribution tissues, delivering reliable protection even under high-load startup conditions. Business Impact → Reduces unplanned outages and equipment wear by delivering predictable fault isolation with a 225 A rating and 200 kAIC fault current capability. Application → Ideal for motor control centers and panel boards in manufacturing and process industries. Feature → Finger Safe construction and Lock-On provision enhance maintenance safety and compliance with lockout-tagout procedures. Business Impact → Improves technician protection and simplifies safe service without compromising uptime. Application → Suitable for daily maintenance and service in harsh industrial environments. Feature → UL98 fusible disconnect and CCC Marked for global compliance. Business Impact → Supports cross-border installations and regulatory adherence, reducing revision work. Application → Global panels and shared equipment across facilities. Feature → Compact footprint with exacting dimensions (2.7 in depth, 3 in width, 3.9 in height). Business Impact → Enables easier retrofits and efficient panel layouts, saving enclosure space and labor costs. Application → Retrofit projects and compact switchgear installations. Feature → Seamless compatibility with Bussmann series protection schemes and thorough datasheet documentation. Business Impact → Streamlines procurement, spares planning, and field support. Application → New builds and upgrades leveraging existing Eaton Bussmann catalog.
Get a Quick Quote for a Eaton CCP2B-3-50CF
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CCP2B-3-50CF?
Enquire Now
FAQs
The CCP2B-3-50CF occupies a compact footprint with a depth of 2.7 inches, width of 3 inches, and height of 3.9 inches. It is designed as a three-pole disconnect suitable for standard industrial mounting patterns and can be integrated into existing Bussmann series protection schemes for straightforward retrofit installations.
This unit is rated for 225 A continuous current, with a short-circuit rating of 200 kAIC and voltage ratings of 600 Vac / 125 Vdc. These specifications support robust isolation and fault protection for demanding motor and industrial power circuits.
CCP2B-3-50CF is part of the Eaton Bussmann family and is designed as a three-pole UL98 fusible disconnect. It is intended to be used with compatible Bussmann fuses and protection schemes; wiring should follow the manufacturer’s installation sheet to ensure correct phase connections and fuse compatibility.
The device is UL98 certified as a fusible disconnect and CCC Marked for compliance in regions that recognize CCC. These certifications support regulatory acceptance for industrial installations and help meet safety and compliance requirements for routine maintenance and service work.
Key safety features include Finger Safe design and a Lock-On provision to facilitate safe maintenance and lockout-tagout procedures. The warranty is Not Applicable, so preventative maintenance and adherence to safety protocols are essential to maximize reliability and minimize downtime in industrial environments.
