Eaton CCP2R-2-100CF Fusible Disconnect - UL98/200kAIC
Part Number: CCP2R-2-100CF
Quick Summary
The Eaton CCP UL98 fusible disconnect provides reliable circuit protection for industrial control panels and motor drives. This compact, two-pole device addresses the common pain point of achieving safe isolation while meeting demanding electrical specs in space-constrained enclosures. It carries UL98 recognition and is designed for 600 Vac and 125 Vdc applications, with a clear specification around 100 A and a robust 200 kAIC short-circuit rating. Beyond safety, the CCP2R-2-100CF supports efficient maintenance workflows and easier fuse replacement, helping you minimize downtime. For engineers and procurement teams, this translates to improved compliance confidence and total-cost-of-ownership benefits when selecting protective disconnects for high-demand environments.
Product Information
Extended Description
CCP2R-2-100CF Eaton: Eaton Bussmann series CCP UL98 fusible disconnect, 600 Vac, 125 Vdc, 100A, UL98 fusible disconnect, Two-pole, 60 Hz, CUBEFuse, 200 - CCP2R-2-100CF
Product Name
Eaton Bussmann series CCP UL98 fusible disconnect
Catalog Number
CCP2R-2-100CF
UPC
051712710008
Product Length/Depth
3.9 in
Product Height
9.5 in
Product Width
3 in
Product Weight
1.43 lb
Warranty
Not Applicable
Certifications
Contact Manufacturer
Amperage Rating
100A
Frequency rating
60 Hz
Short-circuit rating
200 kAIC
Voltage rating
600 Vac, 125 Vdc
Fuse type
CUBEFuse
Number Of Poles
Two-pole
Suitable for fuses
TCF6 to TCF100 TCF1RN to TCF100RN FCF1RN to FCF100RN
CCP2R-2-100CF~2 Pole Comp Ckt Protect 100A
CCP2R-2-100CF~2 Pole Comp Ckt Protect 100A
Eaton Specification Sheet - CCP2R-2-100CF
Feature → Business Impact → Application: The CCP2R-2-100CF is a UL98 fusible disconnect rated for 600 Vac and 125 Vdc, delivering clear isolation and reduced arc-flash risk in industrial panels. This directly improves safety and compliance in motor drives and control circuits, enabling faster maintenance cycles and safer lockout procedures in manufacturing lines. The two-pole design with a 100 A rating supports demanding motor and load switching scenarios, meaning fewer components and simpler wiring schemas for panel builders. In practice, technicians experience streamlined installation and reduced commissioning time thanks to standardized dimensions and the CUBEFuse fuse type, which aligns with common industry fusing practices. The device’s 60 Hz operation and 200 kAIC short-circuit rating further assure resilience in fault conditions, reducing the likelihood of cascading failures in protection schemes. Compatibility with TC and RF fuse families supports broader OEMs’ panel integration and spare-part alignment for mixed fleets.
Get a Quick Quote for a Eaton CCP2R-2-100CF
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CCP2R-2-100CF?
Enquire Now
FAQs
CCP2R-2-100CF is designed for CUBEFuse compatibility and supports fuse ranges specified by Eaton. Typical installation involves mounting the disconnect in a suitable enclosure, wiring per schematic, and inserting CUBEFuse elements that match the 100 A rating. Ensure proper fuse sizing for your load and observe lockout/tagout procedures during replacement to maintain safety and compliance.
The device provides two-pole protection rated for 600 Vac and 125 Vdc, with a 100 A amperage rating, a 60 Hz frequency, and a short-circuit rating of 200 kAIC. These specs support robust protection for heavy-duty industrial circuits and ensure reliable isolation during fault events.
The CCP2R-2-100CF is described as a UL98 fusible disconnect, indicating UL 98-related safety coverage for circuit protection devices. For official listings and regional certifications (such as CE), consult Eaton documentation and local regulatory guidance to confirm applicability in your installation region.
The unit measures 3.9 inches in depth, 9.5 inches in height, and 3 inches in width, with a weight of 1.43 lb. It is a two-pole device designed for straightforward panel mounting in standard industrial enclosures, facilitating clean wiring runs and compact installation.
Using the CCP2R-2-100CF offers fast isolation, improved safety for maintenance personnel, and reduced downtime due to reliable fault interruption. Its compatibility with common fuse families and a robust short-circuit rating help minimize spare-parts diversity, simplify procurement, and support durable lifecycle performance in demanding production environments.
