Eaton CCP2R-2-30CC Fusible Disconnect - 2-Pole UL98
Part Number: CCP2R-2-30CC
Quick Summary
The Eaton CCP2R-2-30CC UL98 fusible disconnect provides safe, dependable circuit protection for industrial panelboards. Engineers often struggle with disconnects that reliably switch both AC and DC loads while meeting strict UL/CSA requirements. This unit delivers UL 98 classification, is a two-pole Class CC fuse disconnect rated for 600 Vac and 125 Vdc with a 200 kAIC short-circuit rating, enabling safe isolation during maintenance and fault events. Designed for Eaton Bussmann protection families, it helps reduce downtime and simplify spare-parts management by delivering fast, code-compliant isolation in manufacturing lines and automated systems. In short, it pairs robust safety with practical installation advantages, supporting compliant, ongoing plant protection and reliability.
Product Information
Extended Description
CCP2R-2-30CC Eaton: Eaton Bussmann series CCP UL98 fusible disconnect, 600 Vac, 125 Vdc, 30A, UL98 fusible disconnect, Two-pole, 60 Hz, Class CC, 200 - CCP2R-2-30CC
Product Name
Eaton Bussmann series CCP UL98 fusible disconnect
Catalog Number
CCP2R-2-30CC
UPC
051712709682
Product Length/Depth
1.9 in
Product Height
3.7 in
Product Width
0.3 in
Product Weight
1.18 lb
Warranty
Not Applicable
Certifications
Contact Manufacturer
Amperage Rating
30A
Frequency rating
60 Hz
Short-circuit rating
200 kAIC
Voltage rating
600 Vac, 125 Vdc
Fuse type
Class CC
Number Of Poles
Two-pole
Suitable for fuses
LP-CC-1/2 to LP-CC-30 KTK-R-1/10 to KTK-R-30 FNQ-R-1/4 to FNQ-R-30
CCP2R-2-30CC~2 Pole Comp Ckt Protect 30A
CCP2R-2-30CC~2 Pole Comp Ckt Protect 30A
Eaton Specification Sheet - CCP2R-2-30CC
Feature → Business Impact → Application: The CCP2R-2-30CC is a UL98 fusible disconnect configured as a two-pole device rated for 30A, offering immediate, visible isolation for both AC and DC circuits. This translates into enhanced personnel safety and reduced risk of arc flash during maintenance, especially in high-energy industrial environments. Application: Use in motor control centers and control panels where fast, reliable disconnection is required to protect equipment and personnel during routine servicing or fault conditions. Feature → Business Impact → Application: Its Class CC fuse compatibility and 600 Vac / 125 Vdc voltage rating support a wide range of fuses and systems, enabling engineers to standardize on a single protective solution across mixed loads. Application: Ideal for industrial automation lines, packaging machinery, and conveyor systems requiring compact, compliant protection with minimal installation footprint. Feature → Business Impact → Application: Short-circuit rating of 200 kAIC provides a high margin for fault currents, improving system resilience and reducing consequence of upstream faults. Application: Suitable for panel installations near power conversion equipment and high-current drives where robust protection is essential. Feature → Business Impact → Application: The product’s small footprint (1.9 in depth, 3.7 in height, 0.3 in width) and weight (1.18 lb) support straightforward mounting and reduced enclosure space. Application: Retrofit projects or new builds with limited panel space, enabling easier field upgrades and lower installation cost. Feature → Business Impact → Application: The CCP series’ compatibility with LP-CC and FNQ/R fuse families simplifies spares strategy and procurement. Application: Use in mixed-fuse environments to streamline stocking, maintenance planning, and service turnaround times.
Get a Quick Quote for a Eaton CCP2R-2-30CC
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CCP2R-2-30CC?
Enquire Now
FAQs
The CCP2R-2-30CC is a two-pole UL98 fusible disconnect designed for panel mounting in industrial enclosures. Its compact footprint (1.9 in depth, 3.7 in height, 0.3 in width) enables installation in tight spaces alongside other protection devices. When wiring, ensure secure lug connections and proper strain relief, and verify compatibility with LP-CC fuse types for streamlined maintenance. Always follow relevant electrical codes and Eaton’s installation recommendations to maximize safety and reliability.
The CCP2R-2-30CC is rated for 30A, 60 Hz operation, with a voltage rating of 600 Vac / 125 Vdc and a short-circuit current rating of 200 kAIC. This makes it suitable for high-current control circuits and mixed-voltage applications common in industrial automation. Use it to isolate circuits safely during maintenance, while meeting UL98 and Class CC fuse standards for dependable protection.
Yes, the CCP2R-2-30CC is listed as suitable for fuses LP-CC-1/2 to LP-CC-30, KTK-R-1/10 to KTK-R-30, and FNQ-R-1/4 to FNQ-R-30, offering broad fuse compatibility. This enables a unified protection strategy across different drive and motor circuits, simplifies spare parts management, and supports code-compliant isolation in mixed-fuse environments.
The CCP2R-2-30CC carries UL98 classification, indicating compliance with established fuse disconnect standards for safe operation in industrial settings. Its two-pole design, Class CC fuse compatibility, and 600 Vac /125 Vdc ratings address common regulatory requirements for motor control centers and panel protections. These certifications help ensure your installation meets electrical safety codes, reduces inspection risk, and supports safe maintenance practices.
Using the CCP2R-2-30CC can reduce downtime by delivering fast, code-compliant isolation during servicing, lowering mean time to repair (MTTR). Its compatibility with common LP-CC and FNQ/R fuse families simplifies spare parts inventory and procurement, while the robust 200 kAIC short-circuit rating enhances system resilience against faults. Over time, this translates to safer maintenance, fewer unscheduled outages, and predictable operating costs.
