Eaton CCP2R-2-30M CCP UL98 fusible disconnect - 120 kAIC
Part Number: CCP2R-2-30M
Quick Summary
CCP UL98 fusible disconnect isolates and protects 30A circuits in industrial control panels. Engineers often battle nuisance trips and downtime when fuses are misapplied or undersized. UL 98 compliance anchors safety testing and reliability, and additional certifications may be available from the manufacturer. Two-pole, 60 Hz operation in a compact footprint reduces panel space, while the 120 kAIC short-circuit rating supports higher fault levels on feeders. From panel builders to maintenance teams, this device adds safety, simplifies compliance documentation, and improves uptime with a straightforward Eaton Bussmann integration for reliable isolation and fast fault response in energized environments. This makes it a dependable choice for engineers seeking reliable isolation and fast fault response in energized environments.
Product Information
Extended Description
CCP2R-2-30M Eaton: Eaton Bussmann series CCP UL98 fusible disconnect, 30A, UL98 fusible disconnect, Two-pole, 60 Hz, Supplemental, 120 - CCP2R-2-30M
Product Name
Eaton Bussmann series CCP UL98 fusible disconnect
Catalog Number
CCP2R-2-30M
UPC
051712709767
Product Length/Depth
1.9 in
Product Height
3.7 in
Product Width
0.3 in
Product Weight
1.18 lb
Warranty
Not Applicable
Certifications
Contact Manufacturer
Amperage Rating
30A
Frequency rating
60 Hz
Short-circuit rating
120 kAIC
Fuse type
Supplemental
Number Of Poles
Two-pole
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - CCP2R-2-30M
30A, two-pole supplemental fuse disconnect provides targeted protection for controlled loads. This arrangement delivers precise overcurrent protection while preserving safe circuit isolation, reducing the risk of arc flash and equipment damage. It’s especially effective for feeders and machine controls in manufacturing lines. Compact footprint advantages: depth 1.9 in, height 3.7 in, width 0.3 in, and weight 1.18 lb. Impact: Frees panel space, simplifies retrofits, and speeds installation. Application: Fits tight control cabinets and standard electrical panels used in automation environments. Electrical performance: 60 Hz operation with a 120 kAIC short-circuit rating. Impact: Withstand high fault currents, safeguarding upstream devices and reducing downstream replacement costs. Application: Suitable for demanding automation lines and process equipment in industrial facilities. Safety certification: UL 98 fusible disconnect classification. Impact: Aligns with safety standards, accelerating compliance documentation and audits. Application: Used across regulated environments; ensure proper labeling and documentation. Product family compatibility: Eaton Bussmann series CCP integrates with nearby fuses and protection devices. Impact: Simplifies procurement and stocking, improves maintenance planning, and supports uniform protection strategy. Application: Ideal for panel builders seeking a cohesive protection solution across a facility. Documentation availability: Catalogs and datasheets for CCP2R-2-30M are readily accessible. Impact: Enables design verification, installation planning, and regulatory review. Application: Download Bussmann catalog no. 1007 and the CCP2R-2-30M datasheet for detailed specifications. The above content emphasizes practical realities—compatibility with Bussmann series, ease of installation in tight panels, and clear protection benefits—while reflecting industry best practices for protection and control devices used in industrial automation.
