Eaton CCP2RL-2-30M Fusible Disconnect - UL98
Part Number: CCP2RL-2-30M
Quick Summary
The Eaton CCP2RL-2-30M Fusible Disconnect delivers reliable circuit isolation for industrial protection panels and control cabinets. This two-pole, 30A device is designed to safely interrupt power while offering straightforward servicing in demanding environments. Engineers often struggle with selecting a disconnect that provides safety and uptime without complicating panel layouts; this model offers a compact footprint and a robust UL98 fusible disconnect design that fits tight enclosures. Its 60 Hz operation and a 120 kAIC short-circuit rating translate into dependable protection during fault events, reducing downstream damage and maintenance costs. With compatibility across Eaton’s Bussmann CCP series and standard panel configurations, it supports efficient installation and predictable performance, lowering procurement risk for panel upgrades.
Product Information
Extended Description
CCP2RL-2-30M Eaton: Eaton Bussmann series CCP UL98 fusible disconnect, 30A, UL98 fusible disconnect, Two-pole, 60 Hz, Supplemental, 120 - CCP2RL-2-30M
Product Name
Eaton Bussmann series CCP UL98 fusible disconnect
Catalog Number
CCP2RL-2-30M
UPC
051712709781
Product Length/Depth
1.9 in
Product Height
3.7 in
Product Width
0.3 in
Product Weight
1.18 lb
Warranty
Not Applicable
Certifications
Contact Manufacturer
Amperage Rating
30A
Frequency rating
60 Hz
Short-circuit rating
120 kAIC
Fuse type
Supplemental
Number Of Poles
Two-pole
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - CCP2RL-2-30M
Feature: Two-pole, 30A rating. Business Impact: Enables quick, safe isolation with a compact footprint. Application: Ideal for small-to-mid-size control panels and motor circuits in manufacturing environments. Feature: UL98 fusible disconnect. Business Impact: Provides recognized safety and easier compliance verification. Application: Industrial protection panels requiring proven fuse-based isolation. Feature: Short-circuit rating of 120 kAIC and 60 Hz operation. Business Impact: Supports selective coordination and rapid fault clearing, reducing arc energy and equipment damage. Application: Power feeds in packaging lines and process controls. Feature: Supplemental fuse type. Business Impact: Allows right-sized protection and safer shutdown without full-load disconnect. Application: Critical loads where selective coordination is desired. Feature: Compact dimensions and lightweight design (1.9 in depth, 3.7 in height, 0.3 in width, 1.18 lb). Business Impact: Eases retrofit projects and minimizes cabinet modification time. Application: Retrofit in existing enclosures or new installations with space constraints. Feature: Compatibility with the Bussmann series and Eaton support. Business Impact: Streamlines procurement and accelerates installation with familiar components. Application: Panel upgrades and new builds across industrial facilities seeking reliable CCP protection.
Get a Quick Quote for a Eaton CCP2RL-2-30M
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CCP2RL-2-30M?
Enquire Now
FAQs
The CCP2RL-2-30M is designed for Eaton Bussmann CCP series panel protection. It fits standard two-pole disconnect applications in industrial control cabinets and can be integrated with CCP-line accessories for corrected mounting and wiring. Compatibility considerations include enclosure depth, mounting hardware, and approved wiring practices per IEC/NEC guidelines.
Key specs include a 30A amperage rating, 60 Hz frequency, and a 120 kAIC short-circuit rating. It is a UL98 fusible disconnect with a supplemental fuse type and two poles, enabling safe isolation and protection for feeder circuits in demanding industrial environments.
The device is specified as a UL98 fusible disconnect, which supports UL-listed protection strategies. Additional certifications may be required for your specific installation; Eaton recommends confirming with the manufacturer or your compliance team to ensure all local and industry-specific marks are met before deployment.
Install with attention to the compact footprint: 1.9 in depth, 3.7 in height, and 0.3 in width. Use correct mounting hardware and follow wiring diagrams for two-pole connections, fuse placement, and labeling. Proper torque on connections and adherence to enclosure clearance will maximize reliability and ease future maintenance.
Benefit comes from safer, faster fault isolation and reduced downtime due to predictable 120 kAIC fault clearing. The compact, lightweight design simplifies retrofits, lowers installation time, and supports proactive maintenance routines, contributing to overall lifecycle cost savings and improved plant safety.
