Eaton CCP2SL-2-30M Fusible Disconnect - UL98 Listed
Part Number: CCP2SL-2-30M
Quick Summary
The Eaton CCP2SL-2-30M fusible disconnect provides reliable circuit protection for compact industrial control panels. Engineers often contend with downtime from nuisance fuse changes and cramped enclosures, making a compact, easy-to-service solution essential. This UL98-listed device supports safe operation at 60 Hz with a two-pole design for clear isolation, helping protect both equipment and personnel. By combining a proven Bussmann series protection approach with straightforward installation, it delivers dependable performance while reducing maintenance cycles. The CCP2SL-2-30M also aligns with common control-panel practices, offering compatibility with standard 30A loads and 120 kAIC fault protection, which translates to lower lifecycle costs and improved system uptime.
Product Information
Extended Description
CCP2SL-2-30M Eaton: Eaton Bussmann series CCP UL98 fusible disconnect, 30A, UL98 fusible disconnect, Two-pole, 60 Hz, Supplemental, 120 - CCP2SL-2-30M
Product Name
Eaton Bussmann series CCP UL98 fusible disconnect
Catalog Number
CCP2SL-2-30M
UPC
051712709828
Product Length/Depth
1.9 in
Product Height
3.7 in
Product Width
0.3 in
Product Weight
1.12 lb
Warranty
Not Applicable
Certifications
Contact Manufacturer
Amperage Rating
30A
Frequency rating
60 Hz
Short-circuit rating
120 kAIC
Fuse type
Supplemental
Number Of Poles
Two-pole
CCP2SL-2-30M~2 Pole Comp Ckt Protect 30A
CCP2SL-2-30M~2 Pole Comp Ckt Protect 30A
Eaton Specification Sheet - CCP2SL-2-30M
Feature → Business Impact → Application: The CCP2SL-2-30M is a two-pole, 30A fusible disconnect, delivering compact footprint and straightforward wiring that saves panel real estate and minimizes installation time in control cabinets. This space efficiency translates to faster commissioning and easier future upgrades in machine terminals and process panels. Feature → Business Impact → Application: The unit is UL98-listed and rated for 60 Hz operation with a 120 kAIC short-circuit rating, elevating fault protection and reducing the risk of arc faults in medium-duty circuits. In practice, this supports safer maintenance and helps meet safety and reliability targets in packaging lines, material handling systems, and packaging machinery. Feature → Business Impact → Application: Supplemental fuse type provides selective coordination with upstream protection, improving system reliability by ensuring only the affected section clears during a fault, which reduces unnecessary downtime in demanding manufacturing environments. Feature → Business Impact → Application: The compact, low-weight design—1.12 lb with dimensions 1.9 in (L) × 3.7 in (H) × 0.3 in (W)—facilitates installation in tight enclosures and retrofits, delivering cost savings on labor and enclosure space in retrofits and new-build panels. Feature → Business Impact → Application: Availability of full catalogs and datasheets accelerates procurement and specification accuracy, reducing design risk for panel builders and integrators working on Eaton Bussmann CCP applications in conveyors, robotics, and automated lines.
Get a Quick Quote for a Eaton CCP2SL-2-30M
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CCP2SL-2-30M?
Enquire Now
FAQs
The CCP2SL-2-30M is a compact, two-pole disconnect that fits standard control panels. With a depth of 1.9 in, height of 3.7 in, and width of 0.3 in, it minimizes enclosure intrusion. Ensure mounting aligns with the panel’s protective interlock and verify clean, accessible fuse access for maintenance and safe disconnection during servicing.
Key ratings include a 30A amperage rating, 60 Hz frequency, and a 120 kAIC short-circuit rating. These specs support reliable protection for mid-range industrial loads while enabling safe fault clearance and compliant operation within typical control circuits.
Yes. With a 30A, 60 Hz rating and a two-pole configuration, the CCP2SL-2-30M is well-suited for machine tool control circuits and other mid-range applications where compact protection and quick isolation are advantageous. Always verify compatibility with upstream protection and panel space constraints.
The device is described as a UL98 fusible disconnect, which supports safety compliance for many industrial panels. For additional approvals such as CE, SIL, or IP ratings, contact the manufacturer to confirm exact certifications and the scope of each approval in your region or industry.
Fuse-based protection enables rapid fault isolation and straightforward fuse replacement, reducing downtime after faults. The compact form factor simplifies installation in crowded panels, lowers labor costs during retrofits, and supports predictable maintenance intervals, contributing to overall site productivity and reduced operating expenses.
