Eaton CHH2070H4X Circuit Breaker - UL 489 Two-Pole
Part Number: CHH2070H4X
Quick Summary
CHH2070H4X is an Eaton thermal magnetic circuit breaker that protects industrial power circuits in panels. Its bolt-on design reduces on-site installation time and helps prevent misalignment in crowded electrical rooms. UL 489 certification ensures safety compliance, while a 42 kAIC interrupt rating and a 70 A rating deliver reliable fault protection for demanding processes. Designed to work with 37MM and 37SS modular metering stacks, this device integrates smoothly with Eaton's protection ecosystem, helping you simplify panel layouts and maintenance. With a limited lifetime warranty and solid electrical performance, CHH2070H4X supports lower total cost of ownership and improved uptime across industrial facilities.
Product Information
Extended Description
CHH2070H4X Eaton: Type CCH Bolt-On Circuit Breaker, Two-Pole, 70A, 120/240V, 42 kAIC
Product Name
Eaton CH thermal magnetic circuit breaker
Catalog Number
CHH2070H4X
UPC
782113032641
Product Length/Depth
4.5 in
Product Height
9.1 in
Product Width
5.3 in
Product Weight
4.4 lb
Warranty
Limited lifetime
Certifications
UL 489
Used with
For use with 37MM and 37SS three-phase modular metering stacks
Amperage Rating
70A
Voltage rating
120/240 V
Mounting Method
Bolt-on
Interrupt rating
42 kAIC
Main circuit breaker
CH
Number of poles
Two-pole
70A rating provides targeted protection for standard loads in 120/240 V systems, delivering reliable performance without encouraging nuisance trips during routine motor starts and loading fluctuations. This selective protection minimizes outages while safeguarding critical equipment, enabling smoother production runs in automation panels and distributed control architectures. 42 kAIC interrupt rating enables robust fault current protection for demanding installations, reducing potential equipment damage and shortening downtime after short-circuit events. This level of interrupt capability supports resilience in harsh industrial environments, where energy levels and motor inrush can challenge standard protection schemes. Bolt-on mounting speeds field installation and simplifies retrofits, helping technicians avoid costly alignment errors and reduce commissioning time in busy electrical rooms. The secure mechanical attachment also improves vibration resistance in factory floors and outdoor installations where equipment is exposed to dynamic loads. Two-pole configuration protects both hot legs, enabling reliable 120/240 V operation and safe handling of multi-wire circuits across single-phase and three-phase systems. This arrangement reduces wiring complexity, supports consistent protection across phase pairs, and simplifies panel planning for large industrial electrical loads. Designed for use with 37MM and 37SS modular metering stacks, CHH2070H4X integrates into Eaton's protection ecosystem with minimal interface issues and predictable spare parts compatibility. Compatibility lowers integration risk, accelerates project timelines, and helps maintenance teams manage inventories in facilities with mixed Eaton protection devices. UL 489 certification confirms compliance with recognized safety standards, reinforcing confidence during audits and inspections in regulated industries like food, pharma, and manufacturing. Coupled with a limited lifetime warranty, the product offers predictable long-term cost of ownership, service planning, and reduced total cost of ownership for asset-intensive operations.
Get a Quick Quote for a Eaton CHH2070H4X
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CHH2070H4X?
Enquire Now
FAQs
The CHH2070H4X is specified for use with 37MM and 37SS three-phase modular metering stacks, enabling seamless integration within Eaton's protection ecosystem. This compatibility reduces interface risks, simplifies wiring schemes, and minimizes retrofit effort during panel upgrades or metering module additions.
CHH2070H4X is a two-pole breaker rated for 70 A and 120/240 V operation, with a 42 kAIC interrupt rating. It features bolt-on mounting for rapid installation and is UL 489 listed, ensuring compliance with recognized safety standards for low-voltage distribution.
Yes, CHH2070H4X carries UL 489 certification. This means the device has been tested for safety and performance in accordance with widely accepted national standards, helping you meet regulatory requirements, pass audits, and reliably protect electrical systems in industrial settings.
The breaker is well suited for distribution panels and service entrances in automation facilities, with 120/240 V single- or multi-wire configurations. Its 70 A rating, 42 kAIC interrupt capacity, and bolt-on form factor make it ideal for motor control centers, panel boards, and metering stacks where quick installation and robust protection are priorities.
CHH2070H4X is backed by a limited lifetime warranty, offering predictable long-term service planning. Routine maintenance involves standard inspection of mounting integrity and contact wear during scheduled panel checks; its UL 489 certification and robust interrupt rating help minimize unforeseen outages and ensure ongoing protection of critical loads.
