Eaton CHP125 Circuit Breaker - UL 489
Part Number: CHP125
Quick Summary
Eaton CHP125 circuit breaker delivers reliable overcurrent protection for Type CH load centers in commercial and light-industrial panels. Nuisance trips and lengthy replacements slow projects; this plug-in CHP125 simplifies upgrading and commissioning. UL 489 certification, HACR rating, and compatibility with Type CH load centers ensure safe, code-compliant protection across typical distribution panels. With a 25 A rating at 120/240 V and wiring for #14-6 AWG Cu/Al, the CHP125 supports modular, standardized electrical protection that reduces spare parts and stocking complexity. This makes it easier for engineers and procurement teams to specify, source, and install reliable protection quickly, while maintaining performance across evolving industrial control and power distribution schemes.
Product Information
Extended Description
CHP125 Eaton: Eaton CH thermal magnetic circuit breaker,Type CHP plug-in circuit breaker,25 A,10 kAIC at 120/240 Vac,Single-pole,120/240V,CHP,#14-6 AWG Cu/Al,CHP,Type CH Loadcenters
Product Name
Eaton CH thermal magnetic circuit breaker
Catalog Number
CHP125
UPC
782113923635
Product Length/Depth
5 in
Product Height
3 in
Product Width
1 in
Product Weight
0.2 lb
Certifications
UL 489
Catalog Notes
HACR Rated
Used with
Type CH Loadcenters
Type
Type CHP plug-in circuit breaker
Amperage Rating
25 A
Voltage rating
120/240 V
Circuit breaker type
CH
Interrupt rating
10 kAIC at 120/240 Vac
Main circuit breaker
CHP
Wire size
#14-6 AWG Cu/Al
Number of poles
Single-pole
Feature: Plug-in CHP125 design. Business impact: enables rapid replacement, lowering downtime and field labor costs. Application: used in Type CH Loadcenters for quick upgrades during panel maintenance. Feature: 10 kAIC interrupt rating at 120/240 VAC. Business impact: improves fault clearance and downstream device protection, supporting NEC compliance. Application: protection of feeders in commercial power distribution within Type CH Loadcenters. Feature: 25 A, 120/240 V, single-pole CH style. Business impact: aligns with common branch circuits, reduces panel diversity, and simplifies inventory. Application: residential and light commercial power distribution in Type CH Loadcenters. Feature: Wire size compatibility #14-6 AWG Cu/Al. Business impact: streamlines wiring harnesses, minimizes mis-sizing, and speeds field terminations. Application: CH Loadcenters and CHP plug-in installations. Feature: UL 489 certification and HACR rated. Business impact: ensures code-compliant, safe operation for HVAC and general-purpose loads. Application: guaranteed performance for mixed mechanical and electrical systems. Feature: Compact dimensions 5 in L × 3 in H × 1 in W at 0.2 lb. Business impact: space-saving installation reduces panel crowding and simplifies retrofits. Application: tight panels and retrofit projects in Type CH Loadcenters.
Get a Quick Quote for a Eaton CHP125
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CHP125?
Enquire Now
FAQs
The CHP125 is a plug-in, single-pole breaker rated at 25 A and 120/240 V, designed for Type CH Loadcenters. Installers should ensure proper alignment with CHP main components, verify conductor sizing to #14-6 AWG Cu/Al, and confirm UL 489 listing. Its HACR rating supports HVAC-related loads, while the 10 kAIC interrupt rating provides robust fault protection during panel maintenance and upgrades.
CHP125 provides a 10 kAIC interrupt rating at 120/240 VAC, meaning it can safely interrupt high fault currents typical in distribution systems without losing protective coordination. This rating helps meet NEC requirements for branch-circuit protection, reduces the risk of arcing damage, and supports reliable operation in commercial and light-industrial panels during fault events.
Yes, the CHP125 is HACR rated, which means it is suitable for circuits that supply heating, air conditioning, and refrigeration equipment. This rating simplifies compliance in buildings with HVAC loads, reduces the need for separate cross-listing, and supports safer, code-conforming protection for mechanical spaces and comfort systems.
CHP125 is designed for Type CH Loadcenters and is intended for use as a plug-in replacement within that family. Compatibility with Type CH Loadcenters ensures consistent electrical protection, streamlined stocking of Type CHP components, and quicker retrofits or upgrades in both new installations and service upgrades.
Official Eaton documentation includes the CHP125 specification sheet and the Type CH circuit breaker warranty. Access the CHP125 datasheet for detailed electrical characteristics and installation notes, and review the warranty document for coverage terms and limits. Both resources help validate compliance, support maintenance planning, and justify lifecycle costs in procurement.
