Eaton CHPV1I Photovoltaic Fuse Holder - 1000 Vdc
Part Number: CHPV1I
Quick Summary
The Eaton CHPV1I photovoltaic fuse holder provides essential single-pole PV protection for solar arrays. Engineers often struggle to match fuse blocks to high‑voltage PV circuits while keeping maintenance quick and safe. When selecting PV protection, buyers look for CE marking, IP-rated enclosures for outdoor exposure, and safety certifications such as SIL or UL. The CHPV1I is designed to streamline installation, improve reliability, and reduce downtime by standardizing connections with the PV Series fuse. This page highlights practical, business-focused benefits of a modular Eaton solution that blends compatibility with efficiency.
Product Information
Extended Description
CHPV1I Eaton: Eaton Bussmann series CHPV photovoltaic fuse block, 1000 Vdc, 30A, Modular, Single-pole
Product Name
Eaton Bussmann series CHPV photovoltaic fuse holder
Catalog Number
CHPV1I
UPC
051712242219
Product Length/Depth
0.001 in
Product Height
0.001 in
Product Width
0.001 in
Product Weight
0.15 lb
Warranty
Not Applicable
Compliances
Contact factory
Amperage Rating
30 A
Voltage rating
1000 Vdc
Number of Poles
Single-pole
Used with
For use with PV Series fuse
Feature: 30 A and 1000 Vdc ratings provide direct PV string protection without extra hardware. Business impact: simplifies protection schemes, lowers installation cost, and reduces fault exposure in high-voltage arrays. Application: ideal for commercial rooftop and utility-scale PV installations where high voltage protection is essential. Feature: Modular single-pole design supports scalable protection with straightforward wiring. Business impact: eases field upgrades, minimizes labor, and simplifies spare parts management. Application: protects PV strings in modular solar arrays with easy expansion. Feature: Compatibility with PV Series fuse ensures procurement consistency and faster replacements. Business impact: reduces stocking complexity and accelerates maintenance cycles. Application: seamless integration within Eaton-based protection ecosystems on solar sites. Feature: Robust construction tailored for PV protection applications enhances reliability. Business impact: lowers downtime and improves safety in harsh environments. Application: suitable for rooftop and outdoor PV installations with modular protection blocks. Feature: Comprehensive documentation and datasheet accessibility speeds engineering approvals. Business impact: shortens procurement cycles and strengthens compliance alignment. Application: used by design engineers during system validation and commissioning.
