Eaton CS415LA Toggle Switch - UL/Fed Spec 6241
Part Number: CS415LA
Quick Summary
The Eaton CS415LA toggle switch is a commercial-grade control device designed for reliable on/off operation of lighting and power circuits in commercial spaces. Engineers often struggle with durability and wiring versatility in high-use environments, driving maintenance costs and downtime. This device carries UL certification, NOM listing, and Federal Specification Classification 6241 05, helping meet strict industry and code requirements. Designed for wall mounting with side-wire connections and copper alloy terminals, it enables fast installation and long-term reliability. Together with its compatibility for light almond finish and four-way switching, this switch supports scalable commercial lighting control. By meeting industry standards, it reduces risk during inspections and supports retrofit projects. Additionally, the 120/277 V rating covers a broad range of commercial circuits.
Product Information
Extended Description
CS415LA Eaton: Toggle Switch, Commercial, Light almond, Screw, Wall, Four-way, Copper alloy, 120/277 Vac, #14-10 AWG, Side wire, .031 in
Product Name
Eaton commercial grade toggle switch
Catalog Number
CS415LA
UPC
032664651113
Product Length/Depth
1.3 in
Product Height
4.19 in
Product Width
1.1 in
Product Weight
0.21 lb
Certifications
UL NOM Federal Specification Classification 6241 05
Voltage rating
120/277 V
Application
Commercial
Wiring method
Side wire
Switch type
Four-way
Mounting method
Wall
Connector type
Screw
Allowable wire size
#14-10 AWG
Torque rating
14 lbf-inch
Terminal enclosure material
Copper alloy
Terminals
0.031 in
Color
Light almond
Feature: Side-wire wiring and screw terminals enable rapid, secure terminations with minimal tool time. Business Impact: This reduces field wiring errors and installation costs while improving conductor integrity in high-traffic commercial spaces. Application: Ideal for wall-mounted, four-way circuits using #14-10 AWG copper conductors in offices, schools, and retail facilities. Feature: 120/277 V rating and four-way switch configuration. Business Impact: Enables flexible multi-location control of lighting without needing multiple device types, simplifying project scopes. Application: Suited for commercial lighting control in corridors, atria, and open-plan offices. Feature: Copper alloy terminals with 0.031 in terminals. Business Impact: Delivers durable, low-resistance connections that resist corrosion and maintain consistent performance over time. Application: Recommends for environments with frequent on/off cycles and vibrations. Feature: Torque rating of 14 lbf-in. Business Impact: Ensures snug connections and reduces loosening from mechanical shocks or building movement. Application: Helpful in retrofit and new construction in commercial spaces. Feature: Wall-mount form factor and light almond color. Business Impact: Fits standard decor and backbox depths while maintaining a clean, professional appearance. Application: Common in wall installations with standard plates in offices and retail. Feature: UL NOM Federal Specification 6241 05 compliance. Business Impact: Streamlines compliance checks and reduces risk during inspections. Application: Essential for regulated projects and government-related facilities. Feature: Physical dimensions 1.3 in depth, 4.19 in height, 1.1 in width. Business Impact: Predictable fit reduces field adjustments and backbox choices. Application: Fits in standard backboxes and office wall assemblies for straightforward retrofits.
Get a Quick Quote for a Eaton CS415LA
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CS415LA?
Enquire Now
FAQs
The CS415LA supports side-wire wiring with screw terminals, and is designed for use with #14-10 AWG copper conductors. This configuration enables straightforward field terminations, reduces wiring errors, and speeds up installation in commercial environments, particularly in wall-mounted applications where space and accessibility are considerations.
The CS415LA is rated for 120/277 V and is intended for commercial lighting control. Its four-way switch configuration supports multi-location control in corridors, open-plan spaces, and other high-traffic commercial applications, allowing centralized management of lighting circuits without multiple device types.
Yes, the CS415LA carries UL listing and NOM listing, along with Federal Specification Classification 6241 05. These certifications help ensure regulatory compliance during inspections and simplify approval processes for regulated projects and government facilities.
The CS415LA measures approximately 4.19 in tall, 1.3 in deep, and 1.1 in wide, with a wall-mount design. These dimensions align with common wall box footprints, supporting straightforward installation in standard commercial backboxes and mounting plates.
Key considerations include using #14-10 AWG conductors with copper alloy terminals, tightening to 14 lbf-in torque, and mounting on a compatible wall surface to minimize vibration and movement. The device’s four-way configuration and durable materials reduce maintenance needs, improving uptime and lowering total cost of ownership in busy facilities.
