Eaton CVH3225KX3 Molded Case Circuit Breaker - UL 489
Part Number: CVH3225KX3
Quick Summary
The Eaton CVH3225KX3 Molded Case Circuit Breaker protects power feeds in industrial MCCs. When panel space and serviceability are tight, choosing a robust MCCB can prevent costly downtime. UL 489 and CSA C22.2 No. 5 certifications ensure safety and compliance, while the CV frame supports reliable 225 A protection. With a 3-pole design and a wide copper/aluminum terminal range, this device streamlines installation in load centers and motor control centers, delivering predictable protection and a lower total cost of ownership.
Product Information
Extended Description
CVH3225KX3 Eaton: Eaton Type CV Molded Case Circuit Switch,Molded case circuit breaker,225 A,Three-pole,#6 - 4/0 Al/Cu,CV,#300 kcmil maximum load
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVH3225KX3
UPC
786685759340
Product Length/Depth
11.68 in
Product Height
6.2 in
Product Width
6.3 in
Product Weight
5.5 lb
Warranty
Limited lifetime
Certifications
CSA Std. C22.2 No. 5 UL 489
Catalog Notes
#300 kcmil options use a terminal shield and add 1.50 inches (38.1 mm) to the length of the breaker
Type
Molded case circuit breaker
Amperage Rating
225 A
Circuit breaker frame type
CV
Terminals
#300 kcmil maximum load
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Three-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVH3225KX3
Feature → Business Impact → Application: The 225 A amperage rating enables high-current protection with reduced nuisance trips, improving overall system availability in heavy-load applications and motor circuits. This translates to measurable efficiency gains and improved uptime in manufacturing lines or processing plants. Feature → Business Impact → Application: Three-pole construction ensures balanced fault isolation across phases, reducing arc flash risk and enabling safer maintenance in compact panel assemblies and control rooms. Feature → Business Impact → Application: CV frame compatibility provides a proven fit within Eaton CV MCCBs and compatible load centers, simplifying replacement and stocking for maintenance teams. Feature → Business Impact → Application: Terminals rated to #300 kcmil maximum load (with a shield for 300 kcmil options) reduces conductor crowding and enables a larger conductor footprint in control panels, cutting wiring time and improving heat dissipation. Feature → Business Impact → Application: Wire size range of #6-4/0 AWG Cu/Al streamlines termination for diverse feeder configurations, reducing engineering time and enabling flexible installation in industrial facilities. Feature → Business Impact → Application: Catalog notes about terminal shield and length addition for 300 kcmil options help installers plan space accurately, preventing field surprises and costly rework. Feature → Business Impact → Application: Certifications including UL 489 and CSA C22.2 No. 5 provide regulatory compliance and warranty confidence, supporting long-term maintenance programs in regulated environments.
