Eaton CVH3225X3 Molded Case Circuit Breaker - 100 kAIC
Part Number: CVH3225X3
Quick Summary
CVH3225X3 is a molded case circuit breaker that protects industrial power distribution panels in commercial and light industrial facilities. Tripping during surges or overloads leads to costly downtime, and this breaker is designed for quick, predictable interruption. It carries CSA C22.2 No. 5 and UL 489 certifications, ensuring regulatory compliance and safer, reliable operation. These attributes, along with a 225 A rating and a CV frame three-pole design, support scalable protection, easier panel integration, and lower total cost of ownership. With easy integration into Eaton load centers and compatibility with Cu/Al conductors up to #6/0 and terminal shields for large feeders, it reduces installation risk and speeds commissioning.
Product Information
Extended Description
CVH3225X3 Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,225 A,100 kAIC,Three-pole,#6 - 4/0 Al/Cu,CV,#300 kcmil maximum load
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVH3225X3
UPC
786685705170
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
5 in
Product Weight
4.4 lb
Warranty
Limited lifetime
Certifications
CSA Std. C22.2 No. 5 UL 489
Catalog Notes
#300 kcmil options use a terminal shield and add 1.50 inches (38.1 mm) to the length of the breaker
Type
Molded case circuit breaker
Amperage Rating
225 A
Circuit breaker frame type
CV
Terminals
#300 kcmil maximum load
Interrupt rating
100 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Three-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVH3225X3
Feature: 225 A continuous rating with 100 kAIC interrupt capacity. Business impact: protects critical feeders from high-energy faults, minimizes arc flash exposure, and reduces downtime in demanding environments. Application: service feeders and distribution panels in manufacturing lines and commercial facilities. Feature: CV molded case breaker with a compact footprint. Business impact: enables efficient panel packing, easier retrofits, and simplified wiring in space-constrained control cabinets. Application: new panel builds and retrofit projects in load centers. Feature: Three-pole CV frame design accommodating three-phase systems. Business impact: balanced protection across all phases, improved coordination, and safer startup sequences. Application: motor control centers and three-phase distribution networks. Feature: Cu/Al terminals rated to #6-4/0 with a maximum 300 kcmil load. Business impact: supports high-current feeder connections, reduces bus bar changes, and streamlines installation. Application: large feeders from main breakers in industrial panels. Feature: Catalog notes and installation considerations for 300 kcmil options, including terminal shields and length adjustments (+1.50 in). Business impact: mitigates fitment risks, ensures compliant enclosure integration, and lowers late-stage rework. Application: when upgrading to larger feeders or retrofitting existing installations. Feature: Certifications UL 489 and CSA C22.2 No. 5. Business impact: ensures regulatory compliance, safer operation, and easier inspection. Application: any SPS, MCC, or panelboard deployment requiring recognized safety standards. Feature: Limited lifetime warranty and Eaton support ecosystem. Business impact: reduces long-term ownership cost and simplifies parts availability. Application: long-term maintenance planning and OEM-aligned replacements.
Get a Quick Quote for a Eaton CVH3225X3
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVH3225X3?
Enquire Now
FAQs
CVH3225X3 is designed for three-pole CV frame installations in Eaton load centers and compatible panels. Mounting follows standard MCCB procedures for molded case breakers, with wiring permitted up to #6-4/0 Cu/Al and a maximum load of 300 kcmil. For 300 kcmil wiring, refer to the catalog notes about using a terminal shield and adding 1.50 inches to the breaker length to ensure proper fitment and spacing.
Key ratings include a 225 A continuous rating and a 100 kAIC interrupt capacity, suitable for protecting feeders and motor circuits. The device is a three-pole molded case breaker with a CV frame, and accepts Cu/Al conductors up to #6-4/0 AWG with terminals rated to the same maximum load. This combination supports reliable short-circuit interruption and coordinated protection in typical industrial panels.
Yes. The CVH3225X3 is a three-pole molded case breaker built for three-phase protection in industrial power distribution. Its CV frame and 225 A rating make it suitable for service feeders and distribution duties in manufacturing lines, packaging, and other heavy-duty environments where reliable interruption is essential for equipment protection and uptime.
CVH3225X3 carries UL 489 and CSA C22.2 No. 5 certifications, signaling compliance with recognized safety and performance standards for low-voltage protection devices. This matters for regulatory approvals, safe commissioning, and audit readiness in industrial facilities and in customer-specified safety programs.
With a limited lifetime warranty and compatibility with standard Eaton components and load centers, CVH3225X3 reduces long-term maintenance costs and parts obsolescence risk. Its durable build and high interrupt rating minimize downtime, contributing to favorable ROI in projects requiring dependable protection and predictable lifecycle costs.
