Eaton CVS2060 Molded Case Circuit Breaker - 42 kAIC
Part Number: CVS2060
Quick Summary
CVS2060 is a molded case circuit breaker that protects industrial electrical panels and switchgear. Professionals often wrestle with nuisance trips and mis-sized protection during upgrades, which can cause downtime and unplanned maintenance. This device carries UL 489 and CSA certification, ensuring safe operation and reliable performance within CV frame panels. With a compact footprint and a limited lifetime warranty, CVS2060 delivers robust main protection while simplifying installation and future service needs. Designed for copper and aluminum conductors from #6 to 4/0 kcmil, it fits common panel schemes and reduces part count. This translates to faster installation, better space utilization, and a clear path to compliant, scalable electrical protection.
Product Information
Extended Description
CVS2060 Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,60 A,42 kAIC,Two-pole,#6 - 4/0 Al/Cu,CV,#6 - 4/0 kcmil line and load
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS2060
UPC
786685705620
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
3.5 in
Product Weight
2.75 lb
Warranty
Limited lifetime
Certifications
CSA Std. C22.2 No. 5 UL 489
Type
Molded case circuit breaker
Amperage Rating
60 A
Circuit breaker frame type
CV
Terminals
#6-4/0 kcmil line and load
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Two-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS2060
Feature 60 A nominal rating with a two-pole CV frame provides precise overload protection while minimizing nuisance disconnections, supporting efficient distribution of loads in load centers. Business Impact: reduces unexpected trips and improves uptime during routine commissioning and routine maintenance. Application: ideal for feeders and branch circuits in industrial panels. Feature 42 kAIC interrupt rating enables fast fault clearance, protecting equipment and reducing arc energy. Business Impact: lowers damage to downstream devices and enhances personnel safety. Application: service panels and critical circuits in industrial facilities. Feature terminals rated for #6-4/0 kcmil Cu/Al allow direct wiring without adapters, simplifying installation and verification. Business Impact: saves time during wiring and reduces termination errors. Application: panel boards and MCCs with common conductor sizes. Feature compact dimensions (7.5 in L × 5 in H × 3.5 in W) and a weight of 2.75 lb support space-saving installations. Business Impact: easier mounting, reduced enclosure crowding, and quicker replacement. Application: retrofit into existing load centers and control panels. Feature UL 489 and CSA Std. C22.2 No. 5 certifications provide proven safety compliance. Business Impact: regulatory alignment and risk mitigation for inspections. Application: industrial protection schemes requiring recognized standards. Feature Limited lifetime warranty lowers life-cycle costs and confirms long-term reliability. Business Impact: predictable maintenance planning and reduced total cost of ownership. Application: continuous operation in demanding environments.
Get a Quick Quote for a Eaton CVS2060
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVS2060?
Enquire Now
FAQs
CVS2060 is a two-pole molded case circuit breaker designed for CV frame panels and compatible load centers. It accepts conductor sizes from #6 to 4/0 kcmil Cu/Al, enabling straightforward integration into Eaton load centers and switchgear without adapters. This makes it a practical tenant main breaker for upgrade projects and new installations alike.
CVS2060 is rated at 60 A with a 42 kAIC interrupt rating. It is a two-pole device in the CV frame family, using terminals sized for #6-4/0 kcmil Cu/Al. These ratings support reliable protection for standard feeder circuits and allow safe operation within industrial panel assemblies.
Yes. CVS2060 carries UL 489 certification and CSA Std. C22.2 No. 5 compliance, ensuring recognized safety and performance for molded case circuit breakers in commercial and industrial environments. This certification supports regulatory adherence and ongoing inspections.
CVS2060 measures 7.5 inches in length, 5 inches in height, and 3.5 inches in width, weighing 2.75 pounds. It is designed for CV frame panels and supports direct wiring with #6-4/0 Cu/Al. When installing, ensure proper torque on terminations and verify compatibility with the panel’s space and mounting provisions to optimize space utilization.
CVS2060 comes with a limited lifetime warranty, offering assurance of long-term reliability and reduced lifecycle costs. This helps maintenance teams plan replacements and ensures consistent protection without frequent equipment changes, contributing to lower total cost of ownership in seasoned electrical installations.
