Eaton CVS2060X Molded Case Breaker - UL 489, 42 kAIC
Part Number: CVS2060X
Quick Summary
The Eaton CVS2060X molded case circuit breaker provides reliable overcurrent protection for low-voltage panels and distribution systems. Engineers often struggle to find a device that handles large conductor sizes, meets strict safety standards, and fits compact spaces. This model carries UL 489 and CSA C22.2 No. 5 certifications with a 42 kAIC interrupt rating, and it uses the CV frame for broad compatibility. In practice, this translates to faster installation, safer panel assemblies, and lower total cost of ownership through durable, standardized design. For procurement and design reviews, you gain traceability and confidence across load centers and motor-control systems. This combination supports compliance audits and reduces field service calls in practice.
Product Information
Extended Description
CVS2060X Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,60 A,42 kAIC,Two-pole,#6 - 4/0 Al/Cu,CV,#4/0 kcmil maximum load
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS2060X
UPC
786685705507
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
3.5 in
Product Weight
2.75 lb
Warranty
Limited lifetime
Certifications
UL 489 CSA Std. C22.2 No. 5
Type
Molded case circuit breaker
Amperage Rating
60 A
Circuit breaker frame type
CV
Terminals
#4/0 kcmil maximum load
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Two-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS2060X
Feature → Business Impact → Application: 60 A amperage rating provides targeted protection for moderate-load panels, enabling engineers to size feeders efficiently while reducing nuisance trips and optimizing breaker coordination in distribution blocks. Application: low-voltage panel boards and small motor control centers benefit from predictable tripping behavior and easier sequence planning. Feature → Business Impact → Application: 42 kAIC interrupt rating delivers robust short-circuit protection, minimizing equipment damage and downtime during fault events. Application: critical feeders in manufacturing lines and utility sub-panels require fast, reliable clearance to avoid cascading faults. Feature → Business Impact → Application: #6-4/0 AWG Cu/Al wire range and #4/0 kcmil terminals support large feeder conductors, simplifying installation and reducing terminal crowding in compact panels. Application: motor starters and large-load feeders in CV frame systems. Feature → Business Impact → Application: UL 489 CSA Std. C22.2 No. 5 certifications provide regulatory alignment, speeding approvals and audit readiness. Application: design-build projects and retrofit programs seeking compliant, traceable protection devices. Feature → Business Impact → Application: two-pole configuration and CV frame compatibility enable straightforward replacement and cross-compatibility in Eaton load centers. Application: quick upgrades and standardized panel builds for commercial and light-industrial environments. Feature → Business Impact → Application: limited lifetime warranty and durable construction lower maintenance costs and extend service intervals. Application: long-term asset management and predictable total cost of ownership across multiple sites.
Get a Quick Quote for a Eaton CVS2060X
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVS2060X?
Enquire Now
FAQs
CVS2060X is designed for low-voltage distribution, including load centers, panelboards, and motor-control centers. It delivers reliable overcurrent protection with a 60 A rating and a 42 kAIC interrupt capability, making it suitable for compact installations where space optimization and safety compliance are priorities.
The CVS2060X provides a 60 A amperage rating, a 42 kAIC interrupt rating, and a two-pole configuration. Termination supports Cu/Al conductors up to #4/0 kcmil, with #6-4/0 AWG wire sizes. This combination suits mid-range loads while maintaining robust protection in CV frame systems.
Yes. CVS2060X is explicitly a CV frame molded case breaker, designed for broad compatibility with Eaton CV-series panels and load centers. Its two-pole configuration and termination specifications ensure straightforward drop-in substitution and consistent performance in existing CV frame installations.
CVS2060X carries UL 489 and CSA Std. C22.2 No. 5 certifications, confirming compliance with recognized safety and performance standards for low-voltage circuit breakers. These certifications support regulatory approvals, audits, and cross-border procurement for global projects.
The CVS2060X carries a limited lifetime warranty, reflecting Eaton's long-term support for its molded case breakers. This warranty, combined with durable construction and standard CV-frame compatibility, translates to lower maintenance costs and predictable asset life across multiple sites.
