Eaton CVS2060XMM Molded Case Circuit Breaker - 42 kAIC
Part Number: CVS2060XMM
Quick Summary
CVS2060XMM is a 60 A molded case circuit breaker that protects CV frame feeders in panelboards and load centers. Engineers often battle nuisance tripping, miscoordination with upstream devices, and lengthy field wiring when upgrading tenant mains. This unit carries UL 489 and CSA Std. C22.2 No. 5 certifications, demonstrating compliance for regulated facilities, plus a limited lifetime warranty for long-term value. With an included mounting kit and straightforward installation, it reduces procurement steps and accelerates commissioning in commercial and light-industrial environments. Designed for flexible integration into load centers and panelboards, CVS2060XMM supports reliable protection without sacrificing space or serviceability.
Product Information
Extended Description
CVS2060XMM Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,60 A,42 kAIC,Two-pole,#6 - 4/0 Al/Cu,CV,#4/0 kcmil maximum load,Includes mounting kit
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS2060XMM
UPC
786685705842
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
3.5 in
Product Weight
2.75 lb
Warranty
Limited lifetime
Certifications
UL 489 CSA Std. C22.2 No. 5
Type
Molded case circuit breaker
Amperage Rating
60 A
Circuit breaker frame type
CV
Accessories
Includes mounting kit
Terminals
#4/0 kcmil maximum load
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Two-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS2060XMM
60 A protection with a CV frame architecture delivers precise protective action for feeders, enabling selective tripping and minimizing downstream outages. The business impact is safer power delivery and improved uptime in busy commercial and light-industrial environments. This configuration is ideal for tenant main breaker roles in load centers where space is at a premium and quick upgrades are common. 42 kAIC interrupt rating ensures reliable interruption of high fault currents without compromising adjacent equipment. That translates to reduced fault energy transfer and enhanced motor and conductor protection. In practice, it's well-suited for distribution panels and service entrances where fault currents are unpredictable. Includes mounting kit simplifies installation and alignment, cutting installation time and reducing mis-wiring risk. The immediate compatibility with standard panel enclosures means less custom hardware and procurement overhead, resulting in faster commissioning and fewer project delays. Wire size compatibility lists #6-4/0 AWG Cu/Al and #4/0 kcmil maximum load on terminals, offering flexible connection options for diverse feeder configurations. This broad range supports easy reuse of existing conductors and simplifies changes during upgrade projects. Compact dimensions—7.5 in deep, 5 in tall, 3.5 in wide—and a 2.75 lb weight make the CVS2060XMM easy to fit in crowded enclosures. Certifications UL 489 and CSA Std. C22.2 No. 5 provide regulatory assurance for installation in North American facilities. An included mounting kit and limited lifetime warranty further reduce total cost of ownership.
Get a Quick Quote for a Eaton CVS2060XMM
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVS2060XMM?
Enquire Now
FAQs
The CVS2060XMM is a two-pole molded case circuit breaker designed for CV frame panelboards. It ships with a mounting kit to simplify alignment and mounting, reduces field wiring complexity, and fits standard enclosure footprints. Verify conductor size compatibility (#6-4/0 AWG Cu/Al) and ensure the maximum load rating (#4/0 kcmil) is observed for safe, code-compliant installation.
CVS2060XMM provides a 60 A rating, a 42 kAIC interrupt capacity, two poles, and accepts conductors #6-4/0 AWG Cu/Al with a maximum load of #4/0 kcmil. It is a CV frame molded case breaker, UL 489 and CSA Std. C22.2 No. 5 certified, designed for reliable protection in distribution panels.
Yes. CVS2060XMM is specifically marketed as a tenant main breaker for CV load centers, offering compact dimensions, mounting kit included, and compatibility with standard panel enclosures. Its 60 A rating and 42 kAIC interrupt capability support safe main protection in commercial and light-industrial applications.
The CVS2060XMM is certified to UL 489 and CSA Std. C22.2 No. 5, ensuring compliance for North American electrical installations and helping meet regulatory requirements for panelboards and load centers.
With mounting kit included, space-efficient design, and a limited lifetime warranty, CVS2060XMM reduces installation time, lowers maintenance downtime, and provides long-term protection for feeders. Its compatibility with common conductor sizes minimizes rewiring costs during upgrades and supports faster ROI in distributed electrical systems.
