Eaton CVS2150X Molded Case Circuit Breaker - 42 kAIC
Part Number: CVS2150X
Quick Summary
The Eaton CVS2150X Molded Case Circuit Breaker provides precise overcurrent protection for low-voltage distribution panels. In practice, downtime and equipment damage often occur when protection devices cannot handle high fault currents or fit within limited panel space. UL 489 and CSA Std. C22.2 No. 5 certifications provide the baseline for compliance; in global markets, CE marking and IP-related expectations often accompany this level of protection. With a compact CV frame, 150 A rating, 42 kAIC interrupt rating, and Cu/Al terminal compatibility, it supports scalable protection while simplifying procurement and installation. Choosing CVS2150X helps reduce downtime and supports compliant, cost-effective panel protection across industrial and commercial applications.
Product Information
Extended Description
CVS2150X Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,150 A,42 kAIC,Two-pole,#6 - 4/0 Al/Cu,CV,#4/0 kcmil maximum load
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS2150X
UPC
786685705569
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
3.5 in
Product Weight
2.75 lb
Warranty
Limited lifetime
Certifications
UL 489 CSA Std. C22.2 No. 5
Type
Molded case circuit breaker
Amperage Rating
150 A
Circuit breaker frame type
CV
Terminals
#4/0 kcmil maximum load
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Two-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS2150X
Feature: Compact CV frame and two-pole design with dimensions of 7.5 in L, 5 in H, and 3.5 in W; Benefit: Space-efficient protection that fits standard panels and enclosures, enabling easy retrofits or new installations in limited compartments; Application: Load centers and panelboards in industrial facilities. Feature: 150 A continuous amperage rating paired with a 42 kAIC interrupt rating; Benefit: Robust fault-current handling reduces arc energy and protects downstream equipment; Application: Main protection in LV distribution networks. Feature: Cu/Al wire compatibility up to #6-4/0 AWG and terminals rated for #4/0 kcmil maximum load; Benefit: Flexible wiring options minimize termination issues and spare parts; Application: Feeder connections to bus bars and field terminations. Feature: UL 489 and CSA Std. C22.2 No. 5 certifications; Benefit: Regulatory compliance and enhanced safety assurance for regulated environments; Application: Industrial, commercial, and light manufacturing panels. Feature: Limited lifetime warranty; Benefit: Long-term value and reduced lifecycle costs; Application: Systems requiring high reliability with predictable maintenance budgeting. Industry context: Compatible with Eaton CV family products, offering a streamlined path for upgrades and standardization across multi-panel installations.
Get a Quick Quote for a Eaton CVS2150X
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVS2150X?
Enquire Now
FAQs
CVS2150X uses the CV frame designed for Eaton molded case breakers and is intended for two-pole installation in CV-series load centers and panelboards. Its compact 7.5 in depth, 5 in height, and 3.5 in width simplify retrofits where space is constrained, while maintaining compliance with UL 489 and CSA standards.
Key specs include a 150 A amperage rating, 42 kAIC interrupt rating, two-pole configuration, and Cu/Al conductor compatibility with #6-4/0 AWG and #4/0 kcmil maximum load. These ensure reliable protection for moderate to heavy fault currents in LV distributions.
Yes. With a high interrupt rating and solid wiring compatibility, CVS2150X is well-suited for protection in industrial control panels, service panels, and load centers requiring dependable main protection in harsh environments.
The CVS2150X is certified to UL 489 and CSA Std. C22.2 No. 5, providing recognized safety and performance benchmarks for low-voltage circuit breakers.
Eaton offers a limited lifetime warranty on the CVS2150X, supporting long-term reliability and reducing lifecycle maintenance costs. For field service, rely on Eaton’s datasheets and distributor support to ensure continued compliance and optimal performance.
