Eaton CVS2175Y Molded Case Circuit Breaker - 42 kAIC
Part Number: CVS2175Y
Quick Summary
The Eaton CVS2175Y Molded Case Circuit Breaker protects electrical systems by interrupting fault currents in commercial and industrial panelboards. Engineers often struggle with selecting a breaker that delivers reliable protection without nuisance trips or oversized cable requirements. UL 489 and CSA C22.2 No. 5 certifications accompany this unit, and its 175 A rating with a 42 kAIC interrupt rating delivers robust safety margins. With copper and aluminum conductor compatibility and a compact footprint, it simplifies installation in existing assemblies and supports scalable distribution strategies for facilities. This translates to lower downtime, easier maintenance planning, and faster commissioning for project teams.
Product Information
Extended Description
CVS2175Y Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,175 A,42 kAIC,Two-pole,#6 - 4/0 Al/Cu,CV,#4/0 kcmil maximum line
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS2175Y
UPC
786685705798
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
3.5 in
Product Weight
2.75 lb
Warranty
Limited lifetime
Certifications
CSA Std. C22.2 No. 5 UL 489
Type
Molded case circuit breaker
Amperage Rating
175 A
Circuit breaker frame type
CV
Terminals
#4/0 kcmil maximum line
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Two-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS2175Y
Feature: Amperage rating of 175 A paired with the CV frame type ensures precise overcurrent protection for feeders up to large loads. Impact: Maintains reliable operation under fault and reduces nuisance trips through consistent trip curves. Application: Ideal as a tenant main breaker in commercial/industrial panelboards where space is limited and reliability is critical. Feature: 42 kAIC interrupt rating provides substantial fault current protection. Impact: Enhances safety margins in high-energy systems and minimizes equipment damage during faults. Application: Suitable for mid-to-large power distribution sections in manufacturing facilities and data centers. Feature: Copper/Aluminum wire compatibility and #6-4/0 AWG terminal range offer flexible wiring options. Impact: Simplifies field wiring, reduces termination errors, and speeds up installation. Application: Useful for OEM panel assemblies and retrofit projects where diverse conductors are present. Feature: Compact 7.5 in x 5 in x 3.5 in footprint and 2.75 lb weight. Impact: Frees panel space, eases handling, and simplifies replacement in crowded enclosures. Application: Ideal for retrofit in existing load centers and new installations with tight dimensions. Feature: UL 489 and CSA C22.2 No. 5 certifications plus limited lifetime warranty. Impact: Ensures regulatory compliance and long-term protection with predictable support. Application: Widely adopted in regulated facilities and certified builds for safe operation and procurement reliability.
Get a Quick Quote for a Eaton CVS2175Y
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVS2175Y?
Enquire Now
FAQs
CVS2175Y uses the CV frame and two-pole configuration, designed for Eaton CV-series panelboards. It accepts #6-4/0 AWG Cu/Al conductors and has a maximum line terminal rating of #4/0 kcmil. This makes it suitable for tenant mains in most standard low-voltage distribution panels, while maintaining straightforward field wiring and torque specifications for reliable long-term performance.
The CVS2175Y has a 42 kAIC interrupt rating, meaning it can safely interrupt fault currents up to 42,000 amperes without damage to the breaker or surrounding components. This provides strong protection for distribution feeders in commercial and light-industrial applications, reducing the risk of equipment damage and enabling safer shutdown during short-circuit events.
Yes. The CVS2175Y is a two-pole, 175 A molded case circuit breaker built on the CV frame, designed for tenant main protection in panelboards and load centers. Its high interrupt rating plus standard UL 489 and CSA certifications supports compliant, reliable protection for distributed circuits while fitting into common panel footprints.
CVS2175Y carries UL 489 and CSA Std. C22.2 No. 5 certifications. These indicate compliance with recognized safety and performance standards for low-voltage circuit breakers, aiding regulatory approvals and procurement qualifications. They are especially important in regulated environments such as data centers, healthcare, and manufacturing facilities where standard-compliant components are required.
The CVS2175Y carries a limited lifetime warranty, providing long-term protection relative to typical field replacements. Maintenance considerations are minimal, but periodic inspection of terminations and torque on connectors is recommended in high-vibration or harsh environments. For critical applications, incorporate routine preventive checks into your site’s maintenance strategy to sustain reliable protection.
