Eaton CVS2200XMM Molded Case Circuit Breaker - 42 kAIC

Feature: 200 A, two-pole molded case breaker in the CV frame. This delivers robust main protection with a compact footprint that saves panel space and reduces wiring complexity. Application: suitable for CV load centers, switchgear, and motor control panels where dependable two-pole protection is required. Feature: 42 kAIC interrupt rating. This capability absorbs high fault currents, minimizes conductor damage, and lowers arc energy in the event of a fault. Application: protective devices for heavy-duty industrial feeders, machine controls, and critical process lines require such margin to meet safety standards. Feature: Wire termination supports #6-4/0 AWG Cu/Al and #4/0 kcmil maximum load. This provides flexible installation options and reduces the need for rewiring when upgrading panels. Application: field wiring for feeders in manufacturing floors, data centers, and HVAC installations. Feature: Includes mounting kit. This simplifies installation, speeds up panel assembly, and reduces commissioning time. Application: new builds and retrofit projects where downtime must be minimized and consistent mounting practices are essential. Feature: Certifications UL 489 and CSA Std. C22.2 No. 5. These certifications ensure compliance with electrical codes and industry standards, facilitating procurement and inspection. Application: industrial and commercial installations requiring recognized safety approvals in North America. Feature: Compact dimensions and weight (7.5 in L, 5 in H, 3.5 in W; 2.75 lb). This improves install ergonomics and panel density, lowering freight and labor costs. Application: panel builders and OEMs who need efficient packaging for CV-frame breakers.
