Eaton CVS2225LL3 Molded Case Circuit Breaker - UL 489/CSA
Part Number: CVS2225LL3
Quick Summary
Eaton CVS2225LL3 Molded Case Circuit Breaker protects power distribution panels by interrupting fault currents in commercial and industrial setups. Engineers often face undersized protection, nuisance trips, and difficult field replacements when upgrading panels; this device offers robust performance and straightforward integration. It carries CSA C22.2 No. 5 and UL 489 certifications, underscoring safety and compliance, while its CV frame compatibility ensures plug-and-play replacement in existing CV panels. Designed for reliability in harsh environments, it helps reduce downtime and maintenance costs. In practice, it's well-suited for load centers, switchgear, and industrial control panels. Its compact footprint also simplifies retrofits in crowded electrical rooms. This aligns with modern safety practices and project timelines.
Product Information
Extended Description
CVS2225LL3 Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,225 A,42 kAIC,Two-pole,#6 - 4/0 Al/Cu,CV,#300 kcmil line and load
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS2225LL3
UPC
786685759197
Product Length/Depth
11.37 in
Product Height
6.2 in
Product Width
6.3 in
Product Weight
4 lb
Warranty
Limited lifetime
Certifications
CSA Std. C22.2 No. 5 UL 489
Type
Molded case circuit breaker
Amperage Rating
225 A
Circuit breaker frame type
CV
Terminals
#300 kcmil line and load
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Two-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS2225LL3
High amperage rating and fault interruption: The CVS2225LL3 delivers 225 A with a 42 kAIC interrupt rating in a compact two-pole CV frame package. This combination reduces exposure time to fault currents, protecting conductors and equipment and reducing the risk of insulation damage. It is ideal for main protection in load centers, motor feeders, and panel boards in industrial facilities. Frame compatibility and installation efficiency: As a CV frame molded case breaker, it integrates with standard CV panel layouts, enabling plug‑and‑play replacements and consistent bus interfaces. This reduces wiring mistakes and commissioning time, delivering faster project turnover and lower installation labor costs. The two‑pole design supports straightforward configuration in shared-neutral or single-circuit applications. Conductor and terminal versatility: Terminals are rated for #6-4/0 AWG Cu/Al and line/load up to #300 kcmil, providing flexibility for wide feeder configurations. This minimizes the need for adapters or rewiring during upgrades, cutting material costs and downtime when integrating with existing feeders or planning future expansion. The design also supports reliable torque and clamp performance across temperatures. Compact footprint and installation ease: With 11.37 in length, 6.2 in height, and 6.3 in width, plus a 4 lb weight, the CVS2225LL3 fits neatly into crowded distribution panels. The smaller footprint enables cleaner wiring routes and faster panel assembly, which is especially beneficial in retrofit projects or limited-space installations. Reliability, warranty, and compliance: A limited lifetime warranty pairs with CSA and UL 489 certifications to provide long-term reliability and regulatory confidence. This combination supports reduced maintenance costs, fewer spare parts, and smoother audits in facilities with stringent electrical safety and performance requirements. Operational resilience for industrial environments: The breaker is designed to perform consistently under typical factory conditions, including temperature variations and vibration. This resilience improves uptime and return on investment across the lifecycle of control panels, switchgear, and downstream distribution equipment.
Get a Quick Quote for a Eaton CVS2225LL3
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVS2225LL3?
Enquire Now
FAQs
To install the CVS2225LL3, locate the CV frame slot in the panel, align the breaker using the standard mounting provisions, and secure it with the appropriate mounting hardware. Connect line and load conductors (#6-4/0 Cu/Al) to the rated terminals (#300 kcmil max), verify tight torques per manufacturer guidelines, and test the trip function with a calibrated test tool to ensure proper operation.
Key specs include a 225 A ampere rating, 42 kAIC interrupt rating, two-pole design, CV frame type, and terminals suitable for #6-4/0 AWG Cu/Al with line/load capacity up to #300 kcmil. These parameters determine protection level, fault clearing capability, and compatibility with existing feeders and panel boards in industrial installations.
Yes. The CVS2225LL3 is certified under UL 489 and CSA standards (CSA C22.2 No. 5), ensuring compliance with recognized safety and performance requirements for low-voltage circuit breakers used in industrial environments. This helps with regulatory audits and ensures dependable protection in critical electrical systems.
Absolutely. With a 225 A rating and 42 kAIC interrupt capability, this breaker provides reliable fault interruption, reducing unplanned downtime. Its durable construction, limited lifetime warranty, and industry certifications translate to lower replacement parts expenditure, fewer nuisance trips, and smoother preventive maintenance cycles across the equipment lifecycle.
The CVS2225LL3 excels in load centers, industrial control panels, and switchgear that require robust main protection for feeders and motor circuits. Its CV frame compatibility and large conductor termination options make it suitable for retrofit projects and new builds in manufacturing, processing, and distribution environments.
