Eaton CVS2225X Molded Case Circuit Breaker - UL 489
Part Number: CVS2225X
Quick Summary
The Eaton CVS2225X Molded Case Circuit Breaker protects electrical circuits in industrial control panels and switchgear. Choosing the right protection for high fault currents and tight installations can delay projects and increase downtime. Certified to CSA Std. C22.2 No. 5 and UL 489, the CV frame delivers reliable two-pole protection up to 225 A with a 42 kAIC interrupt rating. Its compact CV frame lends itself to easier installation in space-constrained panels, while supporting #6-4/0 AWG Cu/Al conductors and straightforward wiring for panel upgrades and automation deployments. This combination supports reliable protection within regulated facilities while enabling scalable panel modernization and easy procurement.
Product Information
Extended Description
CVS2225X Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,225 A,42 kAIC,Two-pole,#6 - 4/0 Al/Cu,CV,#4/0 kcmil maximum load
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS2225X
UPC
786685705590
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
3.5 in
Product Weight
2.75 lb
Warranty
Limited lifetime
Certifications
CSA Std. C22.2 No. 5 UL 489
Type
Molded case circuit breaker
Amperage Rating
225 A
Circuit breaker frame type
CV
Terminals
#4/0 kcmil maximum load
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Two-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS2225X
Feature: The CVS2225X delivers a 225 A amperage rating with 42 kAIC interrupt capacity and a two-pole design provide robust fault protection. Business Impact: This protection reduces arc flash exposure and minimizes equipment damage during fault events, helping to protect personnel and keep lines in production. Application: Well-suited for main feeders and motor circuits in control panels, switchgear, and compact power distribution centers in manufacturing and process environments. Feature: CV frame molded case construction with a compact footprint of 7.5 in length, 5 in height, and 3.5 in width, weighing about 2.75 lb. Business Impact: Smaller form factor simplifies panel layouts, reduces enclosure depth, and speeds installation, enabling faster capital projects and easier retrofits. Application: Fits existing CV-frame panel designs and supports straightforward mounting in space-limited automation cabinets and load centers. Feature: Terminals rated for #4/0 kcmil maximum load and wire size #6-4/0 AWG Cu/Al, with direct termination options. Business Impact: Flexible conductor options minimize sourcing complexity and improve termination reliability, cutting rework and warranty exposure. Application: Ideal for high-current distribution lines in control panels and motor control centers across industrial facilities. Feature: Certifications include CSA Std. C22.2 No. 5 and UL 489, ensuring compliance with major North American safety and performance standards. Business Impact: Streamlines procurement for regulated sectors and reduces qualification time for certification of electrical assemblies. Application: Beneficial for facilities in manufacturing, chemical processing, food and beverage, and infrastructure projects requiring proven protection devices. Feature: Limited lifetime warranty backed by Eaton, with service support and available replacement parts. Business Impact: Improves total cost of ownership by reducing downtime risk and simplifying maintenance planning and spares stocking. Application: Ideal for OEMs building industrial control panels, service providers, and plants pursuing uptime targets.
Get a Quick Quote for a Eaton CVS2225X
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVS2225X?
Enquire Now
FAQs
CVS2225X installs in standard CV-frame control panels with a footprint of 7.5 in length, 5 in height, and 3.5 in width. It is a two-pole device rated 225 A with 42 kAIC and accepts Cu/Al conductors from #6 to 4/0 AWG, with a maximum load of #4/0 kcmil. Ensure the panel cutouts and mounting clearances match the datasheet and follow UL 489 and CSA termination guidelines.
These ratings indicate the device can continuously carry up to 225 A and interrupt fault currents up to 42 kAIC at its rated voltage. For system design, this means robust protection for feeders and motors, improved fault clearing performance, and better coordination with upstream protections, contributing to safer operations and reduced downtime during fault conditions.
This product supports #6-4/0 AWG Cu/Al conductors and terminals rated for a maximum load of #4/0 kcmil. The combination of conductor size, terminal capability, and two-pole CV frame enables flexible wiring options, reduces termination errors, and streamlines field assembly in high-current applications like motor control centers and large power feeds.
CVS2225X carries CSA Std. C22.2 No. 5 and UL 489 certifications, confirming compliance with major North American safety and performance standards. This simplifies supplier qualification, supports code compliance, and reduces risk for regulated facilities in industries such as manufacturing, processing, and infrastructure projects. Selecting a certified breaker standardizes safety practices, speeds inspections, and ensures compatibility with code-based panel assemblies across plant networks.
CVS2225X is covered by a limited lifetime warranty from Eaton, with widely available replacement parts and service support. This reduces lifecycle costs by lowering replacement frequency and simplifying spare part inventories. For maintenance, rely on the simple mechanical design, periodic inspection of terminals, and adherence to installation and safety guidelines to sustain performance over years of operation.
