Eaton CVS3060 Molded Case Circuit Breaker - 42 kAIC
Part Number: CVS3060
Quick Summary
CVS3060 molded case circuit breaker from Eaton protects electrical distribution panels by interrupting overloads in three-phase systems. This unit is designed to simplify main protection in switchboards while delivering dependable performance in a compact footprint. A common pain point is balancing space constraints with high fault-current protection; the CVS3060 addresses this with a CV frame and robust 42 kAIC interrupt rating. It carries UL 489 and CSA certification, underscoring safety and compliance for code-conforming installations. For engineers and procurement teams, the balance of reliability, installation efficiency, and long-term service life translates into lower life-cycle costs. When you need scalable protection for industrial or commercial power distribution, this breaker fits neatly into Eaton-compatible assemblies and panels.
Product Information
Extended Description
CVS3060 Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,60 A,42 kAIC,Three-pole,#6 - 4/0 Al/Cu,CV,#6 - 4/0 kcmil line and load
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS3060
UPC
786685704302
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
5 in
Product Weight
4.4 lb
Warranty
Limited lifetime
Certifications
UL 489 CSA Std. C22.2 No. 5
Type
Molded case circuit breaker
Amperage Rating
60 A
Circuit breaker frame type
CV
Terminals
#6-4/0 kcmil line and load
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Three-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS3060
Feature: 60 A amperage rating and 42 kAIC interrupt rating. Business impact: provides robust short‑circuit protection for distribution feeders, reducing the scope of fault currents and equipment damage. Application: ideal for main protection in three‑phase panels where uptime is critical. Feature: Three‑pole design with CV frame. Business impact: ensures balanced protection across all phases and simplifies coordination with upstream protection. Application: suitable for 480Y/277 V or similar three‑phase systems in industrial and commercial settings. Feature: Terminals sized for #6-4/0 kcmil Cu/Al. Business impact: enables flexible wiring options and reduces termination risk during installation. Application: supports large gauge conductors for fast, compliant connections. Feature: Compact footprint—7.5 in L × 5 in W × 5 in H and 4.4 lb weight. Business impact: saves panel space and simplifies mounting in dense switchgear. Application: panel builders benefit from easier integration and service access. Feature: Certifications UL 489 and CSA. Business impact: assures regulatory compliance and safer operation, easing code approvals. Application: essential for commercial and industrial installations seeking dependable safety validation. Feature: Limited lifetime warranty. Business impact: protects asset investment and lowers total cost of ownership over the product lifecycle. Application: asset management programs benefit from predictable service life and reduced replacement risk.
Get a Quick Quote for a Eaton CVS3060
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVS3060?
Enquire Now
FAQs
Install CVS3060 as a three‑pole main breaker within a CV frame panel. Connect line and load to terminals rated #6-4/0 kcmil Cu/Al, ensuring tight, code‑compliant terminations. Follow Eaton accessory and torque specifications to achieve proper electrical contact and voltage protection with minimal resistance.
CVS3060 provides a 60 A amperage rating with a 42 kAIC interrupt rating. This combination supports effective short‑circuit interruption for most medium‑demand distribution panels, helping to protect downstream equipment while maintaining selectivity with upstream protection.
The CVS3060 is best suited for three‑phase distribution in industrial and commercial environments, including main protection in switchboards and panel boards where space is at a premium. Its CV frame and 60 A rating make it compatible with Eaton CV product families and standard wiring practices.
CVS3060 carries UL 489 and CSA Std. C22.2 No. 5 certifications, confirming compliance with recognized safety and performance standards for molded case circuit breakers. These certifications simplify code approvals, improve procurement confidence, and support safer installation practices.
With a limited lifetime warranty and robust mechanical design, CVS3060 reduces replacement frequency and downtime. Its reliable protection reduces fault‑induced damage, lowers maintenance costs, and extends asset life in panels, contributing to a favorable total cost of ownership over the equipment lifecycle.
