Eaton CVS3060Y Molded Case Circuit Breaker - 42 kAIC
Part Number: CVS3060Y
Quick Summary
Eaton CVS3060Y Molded Case Circuit Breaker protects critical industrial feeders in control panels. Engineers select this device to balance safety, size, and performance under demanding loads. The CV frame and three-pole design simplify panel wiring while delivering reliable protection. However, choosing a breaker that fits CV mounting rails and meets short-circuit requirements can slow project schedules. UL 489 and CSA Std. C22.2 No. 5 certifications guarantee spark-safe operation and regulatory compliance, reducing audit risk. The CVS3060Y also supports common low-voltage protection strategies, helping maintenance teams standardize components across facilities and streamline procurement, installation, and future expansions. With a 60 A rating and 42 kAIC interrupt capacity, it accommodates typical industrial loads while preserving service continuity.
Product Information
Extended Description
CVS3060Y Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,60 A,42 kAIC,Three-pole,#6 - 4/0 Al/Cu,CV,#4/0 kcmil maximum line
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS3060Y
UPC
786685704401
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
5 in
Product Weight
4.4 lb
Warranty
Limited lifetime
Certifications
CSA Std. C22.2 No. 5 UL 489
Type
Molded case circuit breaker
Amperage Rating
60 A
Circuit breaker frame type
CV
Terminals
#4/0 kcmil maximum line
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Three-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS3060Y
Feature → Business Impact → Application: The CVS3060Y uses a CV frame molded case circuit breaker design rated at 60 A with a 42 kAIC interrupt rating, delivering robust short-circuit protection while maintaining a compact footprint. Business impact includes reduced risk of panel-wide outages and improved uptime for critical equipment; this is ideal for industrial control panels and load centers where space is at a premium and reliability is non-negotiable. Application-wise, the three-pole configuration supports balanced three-phase protection for motor controls and process lines, with #4/0 kcmil maximum line terminals and #6-4/0 AWG copper/aluminum wiring enabling straightforward, code-compliant wiring topologies.
Get a Quick Quote for a Eaton CVS3060Y
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVS3060Y?
Enquire Now
FAQs
CVS3060Y installs on standard CV frame mounting rails in three-pole configurations. Ensure adequate clearance for wiring access and heat dissipation; use the device’s 7.5 inch depth and 5 inch width/height footprint to plan enclosure space. Termination supports #4/0 kcmil maximum line with #6-4/0 AWG Cu/Al conductors, and grounding per your panel design. Follow UL 489 wiring guidance for short-term maintenance access and verify torque specifications on all lugs during final assembly.
The CVS3060Y provides a 60 A continuous rating with a 42 kAIC interrupt capacity, and it is a three-pole CV frame device. This pairing supports effective protection for three-phase loads while tolerating moderate fault currents without nuisance tripping. Use it for motor starting scenarios and load centers where peak fault currents approach industry norms, ensuring your protection scheme aligns with system short-circuit levels.
CVS3060Y carries UL 489 and CSA Std. C22.2 No. 5 certifications, signaling compliance with safety, performance, and electrical installation standards. These approvals are critical for regulated facilities, meet procurement requirements, and simplify third-party inspections. Relying on UL/CSA-certified devices reduces audit findings and helps ensure safe operation across industrial environments.
CVS3060Y is designed for industrial low-voltage protection within CV frame control panels and load centers. Its 60 A rating, 42 kAIC interrupt capacity, and three-pole configuration make it suitable for motors, conveyors, and process lines found in heavy industry. It is less typical for residential panels, where smaller ratings and different frame types may apply.
With a limited lifetime warranty and robust UL/CSA certifications, CVS3060Y supports long-term reliability while reducing maintenance downtime. Its compact footprint saves panel space, simplifying future expansions and reducing install labor. Standardized CV-frame breakers enable streamlined parts stocking and faster replacements, driving favorable total cost of ownership in mid- to large-scale industrial installations.
