Eaton CVS3200X3 Molded Case Circuit Breaker - 42 kAIC CSA/UL
Part Number: CVS3200X3
Quick Summary
CVS3200X3 Molded Case Circuit Breaker protects industrial power distribution panels from overload and short circuits. Too often engineers confront nuisance trips and wiring compatibility gaps when upgrading or expanding systems. With CSA Std. C22.2 No. 5 and UL 489 certifications, this Eaton MCCB supports code-compliant installation in commercial and industrial facilities. The device delivers reliable fault protection, shared with limited lifetime warranty, and easy wiring for panel builders. Benefiting projects in load centers, switchgear, and commercial feeders, it reduces downtime and supports scalable, safe expansion. Engineers appreciate the 7.5 inch depth, 5x5 inch footprint, and 200 A rating that align with common panel drawings and field wiring practices.
Product Information
Extended Description
CVS3200X3 Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,200 A,42 kAIC,Three-pole,#6 - 4/0 Al/Cu,CV,#300 kcmil maximum load
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS3200X3
UPC
786685704289
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
5 in
Product Weight
4.4 lb
Warranty
Limited lifetime
Certifications
CSA Std. C22.2 No. 5 UL 489
Catalog Notes
#300 kcmil options use a terminal shield and add 1.50 inches (38.1 mm) to the length of the breaker
Type
Molded case circuit breaker
Amperage Rating
200 A
Circuit breaker frame type
CV
Terminals
#300 kcmil maximum load
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Three-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS3200X3
Feature: 200 A rating with 42 kAIC interrupt capacity. Business Impact: Provides robust protection against high fault currents, reducing downstream damage and maintenance costs. Application: Ideal for main feeders in industrial panels and service equipment where reliability is critical. Feature: Three-pole CV frame with Cu/Al terminals up to #6-4/0 AWG. Business Impact: Simplifies field wiring and enables direct connection to large conductors, lowering install time and error potential. Application: Suitable for heavy-load panels and load centers. Feature: #300 kcmil maximum load option with terminal shield caution. Business Impact: Supports large utility feeds while maintaining safe clearance; catalog note helps plan installations. Application: Heavy-duty feeders in manufacturing environments. Feature: Compact footprint 7.5 in depth and 5x5 in footprint; Weight 4.4 lb. Business Impact: Easier retrofit and cabinet packing, reducing labor and space constraints. Application: Retrofit projects and new builds with tight enclosure spaces. Feature: Certifications CSA UL 489 and limited lifetime warranty. Business Impact: Ensures regulatory compliance and long-term reliability, lowering risk during audits. Application: Industrial and commercial power distribution requiring dependable protection.
Get a Quick Quote for a Eaton CVS3200X3
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton CVS3200X3?
Enquire Now
FAQs
CVS3200X3 is a 200 A, three-pole molded case circuit breaker built on the CV frame, designed for direct integration into CV-frame panelboards and Eaton load centers. It supports Cu/Al conductors up to #6-4/0 AWG and provides a clear path for field wiring. Note the #300 kcmil option requires a terminal shield and adds length, so plan panel depth accordingly. This makes retrofit and new-install projects straightforward while maintaining code-compliant terminations.
Key specs include a 200 A rating, 42 kAIC interrupt capacity, three-pole configuration, CV frame, and copper/aluminum terminals up to #6-4/0 AWG, with maximum load to #300 kcmil. Physical dimensions are a 7.5 inch depth and a 5x5 inch footprint, weighing 4.4 lb. These figures support safe, predictable protection in industrial power distribution and align with UL 489 and CSA C22.2 requirements.
Yes. The CVS3200X3 is described as the CCV tenant main breaker and is applicable as a tenant main in service equipment within load centers and panel boards. It provides robust fault interruption (42 kAIC) for large feeders, while its 200 A rating supports typical service entry and distribution needs. When integrating as a tenant main, verify panel compatibility and shielding requirements if using the 300 kcmil terminal option.
CVS3200X3 carries CSA Std. C22.2 No. 5 and UL 489 certifications, ensuring conformity to recognized safety and performance standards for low-voltage distribution devices. These certifications facilitate code-compliant installations in North American facilities, simplify inspections, and support safe operation across manufacturing, data centers, and commercial buildings. The accompanying limited lifetime warranty further reinforces long-term reliability in demanding environments.
Key considerations include understanding the terminal options: Cu/Al conductors up to #6-4/0 AWG, with a possible #300 kcmil maximum load that requires a terminal shield and increases length by 1.50 inches. Plan for panel depth (especially when using the shield option) and ensure the enclosure supports a three-pole device. Follow UL 489/CSA C22.2 guidelines for torque and connection standards to maintain warranty and code compliance.
