Eaton CVS3225X3 Molded Case Circuit Breaker - 42 kAIC
Part Number: CVS3225X3
Quick Summary
Eaton CVS3225X3 Molded Case Circuit Breaker is a 225 A CV-frame main protection device for electrical distribution panels and industrial control centers. Engineers often face tight spaces, large conductor runs, and strict panel-certification requirements during upgrades or new builds. This breaker is CSA Std. C22.2 No. 5 and UL 489 certified, underscoring safety and performance commitments. With a three-pole design, 42 kAIC interrupt rating, and compatibility with #6-4/0 AWG Cu/Al conductors and up to #300 kcmil terminals, it enables robust protection while simplifying wiring, testing, and maintenance in demanding industrial environments.
Product Information
Extended Description
CVS3225X3 Eaton: Eaton Type CV Molded Case Circuit Breaker,Molded case circuit breaker,225 A,42 kAIC,Three-pole,#6 - 4/0 Al/Cu,CV,#300 kcmil maximum load
Product Name
Eaton CCV tenant main breaker
Catalog Number
CVS3225X3
UPC
786685704296
Product Length/Depth
7.5 in
Product Height
5 in
Product Width
5 in
Product Weight
4.4 lb
Warranty
Limited lifetime
Certifications
CSA Std. C22.2 No. 5 UL 489
Catalog Notes
#300 kcmil options use a terminal shield and add 1.50 inches (38.1 mm) to the length of the breaker
Type
Molded case circuit breaker
Amperage Rating
225 A
Circuit breaker frame type
CV
Terminals
#300 kcmil maximum load
Interrupt rating
42 kAIC
Wire size
#6-4/0 AWG Cu/Al
Number of poles
Three-pole
Residential and Light Commercial, Load centers and Circuit Breakers, Volume 1 Tab 1
Eaton Specification Sheet - CVS3225X3
Feature: CV frame molded case construction delivers consistent trip performance under fault conditions, enhancing system reliability. Business Impact: reduces unplanned downtime and supports predictable maintenance schedules. Application: main protection in load centers and factory panels, aligning with long-term uptime goals. Feature: 225 A amperage rating provides ample headroom for peak loads without nuisance trips. Business Impact: improved load balancing and safer distribution of electrical capacity. Application: feeders to motors and process lines in manufacturing facilities seeking scalable protection. Feature: 42 kAIC interrupt rating enables rapid clearance of high-energy faults. Business Impact: minimizes damage to equipment and wiring, lowering repair costs. Application: facilities with high fault-current scenarios or adjacent power sources. Feature: Terminals rated for #300 kcmil maximum load and wire sizes #6-4/0 AWG Cu/Al. Business Impact: supports large conductor lengths and reduces terminal overheating risk, improving reliability. Application: main breakers in heavy-duty load centers and switchboards.Feature: Catalog notes require a terminal shield for 300 kcmil options, adding 1.50 inches to the breaker length. Business Impact: enhances safety and clearance, simplifying integration with shielded bus duct. Application: projects using 300 kcmil feeders in constrained panels. Feature: Limited lifetime warranty with CSA and UL certifications. Business Impact: lowers total cost of ownership through long-term assurance and fewer replacement cycles. Application: long-run installations in regulated industries such as material handling and process automation.
