Eaton DCG3061FPM DC disconnect - 600 VDC, NEMA 4
Part Number: DCG3061FPM
Quick Summary
The Eaton DCG3061FPM DC disconnect provides safe, reliable isolation for solar PV systems in industrial and commercial installations. This unit helps prevent arc-flash and backfeed during maintenance by offering a robust, external isolation point. It addresses common challenges such as weather exposure, wiring complexity, and code compliance in rooftop and ground-mounted arrays. With UL 98B and NEC 690 per UL 1741 compliance and a NEMA 4 painted galvanized steel enclosure, it meets stringent safety and environmental requirements while remaining easy to install and service. For EPCs and integrators, this heavy-duty DC disconnect delivers predictable performance, long service life, and straightforward documentation, supporting efficient project delivery and lifecycle cost control.
Product Information
Extended Description
DCG3061FPM Eaton: Eaton heavy-duty DC disconnect,30A,Solar,Painted steel,Fusible,Grounded,In/Out(LC): #2-#14 AWG, In/Out(SR): 1/0-#14 AWG,600 Vdc,NEMA 4,3,Fusible,Isolated return,Three-pole,DC photovoltaic applications,Single-throw
Product Name
Eaton heavy duty DC disconnect
Catalog Number
DCG3061FPM
UPC
786685556796
Product Length/Depth
10.22 in
Product Height
19.08 in
Product Width
8.76 in
Product Weight
21 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL 98B NEC 690 per UL 1741
Catalog Notes
Not all configurations for ampere rating and number of circuits are available. All circuit configurations can be found in the product dimension tables.
Type
DC disconnect/grounded system
Amperage Rating
30A
Number of circuits
3
Ground
Grounded
Maximum voltage
600 VDC
NEMA rating
NEMA 4
Protection
Fusible
Application
Solar
Main lug wire size
In/Out(LC): #2-#14 AWG, In/Out(SR): 1/0-#14 AWG
Number of poles
Three-pole
System voltage
600 VDC per pole
Voltage rating
600 VDC
Series
DC photovoltaic applications
Enclosure
NEMA 4
Enclosure material
Painted galvanized steel
Fuse configuration
Fusible
Isolation
Isolated return
Switch type
Heavy duty safety Single-throw DC photovoltaic systems
Protection
Fusible
Feature: 30A amperage rating supports moderate PV array protection with compact, three-pole isolation. Business Impact: Enables safe disconnection during maintenance and reduces risk of arcing, improving worker safety and uptime. Application: Ideal for solar installations where a fusible, grounded, isolated-return disconnect is required. Feature: Three-pole design ensures simultaneous disconnection of all conductors, simplifying compliance and fault handling. Business Impact: Reduces switching transients and simplifies wiring analysis for inspectors and service teams. Application: Suitable for 600 VDC PV circuits and multi-string configurations. Feature: Fusible protection with isolated return increases fault isolation effectiveness. Business Impact: Enhances safety margins in high-energy PV systems and supports NEC compliance. Application: Critical for outdoor PV installations subject to environmental exposure. Feature: NEMA 4 rated enclosure in painted galvanized steel provides weather resistance. Business Impact: Allows outdoor, rooftop, and harsh-environment deployments with consistent performance. Application: Outdoor solar array protection where ingress protection and corrosion resistance matter. Feature: In/Out wiring accommodates LC (#2-#14 AWG) and SR (1/0-#14 AWG) terminations. Business Impact: Flexible wiring options reduce field modification needs and installation time. Application: Panels and disconnects with varied conductor sizes. Feature: Documentation and certification alignment (UL 98B, NEC 690 per UL 1741) streamlines compliance reviews. Business Impact: Accelerates permitting and reduces project risk. Application: Solar projects seeking standard-compliant DC switching solutions.
