Eaton DFJ-125 High Speed Fuse - 200 kAIC at 600 Vac
Part Number: DFJ-125
Quick Summary
DFJ-125 high speed fuse from Eaton provides fast overcurrent protection for industrial control panels and motor drives. This helps minimize nuisance trips and unplanned downtime caused by transient faults and misapplied protection. UL Listed, CSA Certified, and CE RoHS compliant, the DFJ series meets safety, regulatory, and environmental requirements for global facilities. The fuse’s blade-end, Class J design in a melamine tube supports compact, robust installations, while a standard 6 in length simplifies replacement and sourcing across Eaton’s Bussmann family, enabling consistent spare parts management and streamlined procurement.
Product Information
Extended Description
DFJ-125 Eaton: Eaton Bussmann series DFJ high speed fuse, 600 Vac or less, 450 Vdc or less, 125A, 200 kAIC at 600 Vac, 100 kAIC 450 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Class J, Melamine tube
Product Name
Eaton Bussmann series DFJ high speed fuse
Catalog Number
DFJ-125
UPC
051712653435
Product Length/Depth
6 in
Product Height
1.73 in
Product Width
1.73 in
Product Weight
0.76 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Amperage Rating
125 A
Interrupt rating
200 kAIC at 600 Vac 100 kAIC 450 Vdc
Voltage rating
600 Vac or less, 450 Vdc or less
Material
Melamine tube
Packaging type
Standard
Class
Class J
Connection
Blade end x blade end
Fuse indicator
Non Indicating
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - DFJ-125
DFJ-125~DRIVE FUSE
Datasheet - FNQ-30
125 A amperage rating with a 200 kAIC interrupt rating at 600 Vac delivers fast fault clearance, reducing system collateral damage and downtime in drive panels and control cabinets. Business impact: higher line availability and protected downstream components; application: motor drives, servo panels, and automation enclosures requiring reliable high-speed protection. The device supports 450 Vdc limits and 600 Vac or less, enabling cross‑category use in mixed AC/DC systems without guessing the protection settings. Business impact: simplified design choices and improved compliance for mixed-voltage architectures; application: electrical panels and machine control assemblies needing versatile protection. Construction features a non-indicating blade-end design on a melamine tube with Class J rating in a 6 in form factor. Business impact: straightforward field replacement, reduced inventory complexity, and compatibility with standard fuse holders; application: retrofit projects and new builds across industrial automation. Certifications include UL Listed, CSA Certified, and CE RoHS compliant. Business impact: regulatory acceptance in global projects and streamlined supplier qualification; application: international installations and supply chain consistency. The Bussmann series compatibility ensures easy sourcing, standardized spares, and cohesive procurement across plant networks. Business impact: lower total cost of ownership and faster maintenance cycles; application: large-scale deployments in electrical protection and circuit control.
Get a Quick Quote for a Eaton DFJ-125
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton DFJ-125?
Enquire Now
FAQs
The DFJ-125 uses blade-end x blade-end connections and a 6 inch length, designed for standard fuse holders and Class J panels. Ensure compatibility with Melamine-tube fuses and verify clearance for 600 Vac applications. Confirm the holder’s physical fit and electrical clearance to avoid contact or arcing.
The fuse is rated for 125 A with an interrupt rating of 200 kAIC at 600 Vac and up to 450 Vdc. It is designed for 600 Vac or less and supports Class J protection, offering fast fault interruption for high‑speed protection needs in electrical protection and circuit control.
Yes. Its high-speed interruption (200 kAIC) at 600 Vac and blade-end Class J design make it ideal for motor drive panels and servo systems where rapid fault clearance minimizes downtime and prevents damage to drives and power supplies.
The DFJ-125 is UL Listed, CSA Certified, and CE RoHS compliant. These certifications support safety compliance, regulatory acceptance, and environmental responsibility across global installations.
The fuse aligns with standard Bussmann series parts, enabling easier procurement and consolidation of spares. Its durable Class J, non-indicating design and 6 inch form factor simplify replacements, reducing downtime, avoiding mismatched protections, and lowering lifecycle costs in automation environments.
