Eaton DFJ-17.5 high-speed fuse - 200 kAIC at 600 Vac
Part Number: DFJ-17.5
Quick Summary
The Eaton DFJ-17.5 high-speed fuse is a fast-acting overcurrent protection device designed for industrial control panels and motor circuits. It helps prevent equipment damage and unplanned downtime by clearing faults quickly, even in demanding environments. This Class J fuse is CSA Certified and UL Listed, with CE marking and RoHS compliance, ensuring global safety and procurement confidence. Its ferrule-end connections and melamine tube support reliable field installation, while a clear 17.50A rating aligns with precise protection coordination. For panel builders and MRO teams, DFJ-17.5 delivers consistent protection with low total cost of ownership across legacy and modern automation architectures.
Product Information
Extended Description
DFJ-17.5 Eaton: Eaton Bussmann series DFJ high speed fuse, 600 Vac or less, 450 Vdc or less, 17.50A, 200 kAIC at 600 Vac, 100 kAIC 450 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end, Class J, Melamine tube
Product Name
Eaton Bussmann series DFJ high speed fuse
Catalog Number
DFJ-17.5
UPC
051712653299
Product Length/Depth
0.74 in
Product Height
2.27 in
Product Width
0.74 in
Product Weight
0.9 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
CSA Certified UL Listed
Amperage Rating
17.50A
Interrupt rating
100 kAIC 450 Vdc 200 kAIC at 600 Vac
Voltage rating
600 Vac or less, 450 Vdc or less
Material
Melamine tube
Packaging type
Standard
Class
Class J
Connection
Ferrule end x ferrule end
Fuse indicator
Non Indicating
Bussmann series complete full line catalog no. 1007
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - DFJ-17.5
Feature → Business Impact → Application: The DFJ-17.5’s Class J, high-speed design delivers precise short-circuit interruption, reducing arc flash exposure and enabling tighter protection coordination in motor drives and control panels. This directly translates to fewer nuisance trips and longer equipment life, saving maintenance time and spare parts costs in high-volume manufacturing cells. Application: motor drives, CNC machines, and automated assembly lines where fast fault clearance protects costly loads. Feature → Business Impact → Application: 17.50A rating with 200 kAIC at 600 Vac and 100 kAIC at 450 Vdc ensures robust protection across mixed AC/DC circuits, improving selectivity and limiting fault propagation. Application: cross-voltage protection schemes in automation cabinets. Feature → Business Impact → Application: Ferrule-end x ferrule-end connections enable quick, reliable terminations in panel boards, reducing installation time and tightening vibration resistance in rugged environments. Application: service panels and field retrofit projects. Feature → Business Impact → Application: Non-indicating design minimizes maintenance points and simplifies replacement in high-density layouts, while the melamine tube provides chemical resistance and durability. Application: hazardous or space-constrained control panels. Feature → Business Impact → Application: Compliance with CE Mark, RoHS, CSA, and UL supports global manufacturing standards, easing supplier qualification and audit readiness. Application: multinational facilities, OEM builds, and regulated industries.
Get a Quick Quote for a Eaton DFJ-17.5
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton DFJ-17.5?
Enquire Now
FAQs
Install by confirming the panel is within 600 Vac or 450 Vdc ratings and that ferrule-end conductors are compatible with Class J devices. Use ferrule-end x ferrule-end terminations and follow standard safety procedures. Ensure the fuse aligns correctly with the holder, then secure without over-tightening to maintain reliable contact and vibration resistance.
The DFJ-17.5 provides a 17.50A rating, with an interrupt rating of 200 kAIC at 600 Vac and 100 kAIC at 450 Vdc. It is rated for 600 Vac or less and 450 Vdc or less, Class J, with ferrule-end connections and a melamine tube, designed for high-speed fault clearing.
Yes. The device accommodates 600 Vac or less and 450 Vdc or less, with an interrupt rating that supports robust protection for mixed AC/DC motor drive and control circuits, making it suitable for a wide range of industrial applications.
Yes. The DFJ-17.5 carries CE marking and RoHS compliance, and is CSA Certified and UL Listed, providing broad regulatory acceptance for global manufacturing and installation in compliant environments.
Non-indicating fuses reduce potential failure points and simplify visual inspection in tight panel layouts. Combined with a reliable 17.50A rating and high interrupt capability, this can lower maintenance time and spare-part inventory while improving uptime in automated lines.
