Eaton DFJ-175 High Speed Fuse - UL Listed
Part Number: DFJ-175
Quick Summary
DFJ-175 by Eaton high speed fuse protects motor drives and control circuits up to 600 Vac. It rapidly interrupts fault currents to minimize arcing, equipment damage, and downtime. Engineers frequently contend with nuisance trips and slow protection, which disrupts productivity; this fuse is designed to respond quickly while remaining easy to install in standard panels. The DFJ-175 carries UL Listed and CSA Certified marks, plus CE Marked RoHS compliance, supporting regulatory alignment for global deployments. With a compact 1 in length profile and blade-end connections, it fits tight enclosures and simplifies field wiring. In practice, users gain shorter maintenance windows, improved system reliability, and a lower total cost of ownership across diverse industrial applications.
Product Information
Extended Description
DFJ-175 Eaton: Eaton Bussmann series DFJ high speed fuse, 600 Vac or less, 450 Vdc or less, 175A, 200 kAIC at 600 Vac, 100 kAIC 450 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Class J, Melamine tube
Product Name
Eaton Bussmann series DFJ high speed fuse
Catalog Number
DFJ-175
UPC
051712653459
Product Length/Depth
1 in
Product Height
0.5 in
Product Width
3 in
Product Weight
0.754 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
CSA Certified UL Listed
Amperage Rating
175 A
Interrupt rating
200 kAIC at 600 Vac 100 kAIC 450 Vdc
Voltage rating
600 Vac or less, 450 Vdc or less
Material
Melamine tube
Packaging type
Standard
Class
Class J
Connection
Blade end x blade end
Fuse indicator
Non Indicating
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - DFJ-175
DFJ-175~DRIVE FUSE
Datasheet - FNQ-30
Amperage rating of 175 A with an interrupt rating of 200 kAIC at 600 Vac and 100 kAIC at 450 Vdc delivers dependable protection for demanding loads, reducing arc energy and extending equipment life. This directly lowers downtime and maintenance costs while supporting fast, repeatable replacements in mission-critical panels. The Class J construction, blade end x blade end connections, and melamine tube enable straightforward installation in existing enclosures and switchgear, minimizing wiring complexity and project lead times. Compliance with CE Marked RoHS, along with CSA Certified and UL Listed labels, ensures market access and traceability for regulatory audits. The compact 1 in L × 3 in W × 0.5 in H form factor and non-indicating design simplify integration in dense control racks and automated lines. Overall, the DFJ-175 balances rugged protection with cost-efficient deployment in modern industrial settings.
Get a Quick Quote for a Eaton DFJ-175
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton DFJ-175?
Enquire Now
FAQs
DFJ-175 uses blade end x blade end connections designed for quick panel mounting. Plan for a standard 1 in length, ensure sufficient clearance in dense enclosures, and verify compatible Class J holders. Use proper torque on blade terminals to maintain reliable contact and minimize contact resistance, enabling consistent protection in motor drives and control circuits.
Yes. The DFJ-175 is rated for 600 Vac or less and 450 Vdc or less, with an interrupt rating of 200 kAIC at 600 Vac and 100 kAIC at 450 Vdc. This makes it suitable for mixed AC/DC protection schemes in modern automation gear, including drives and switchgear, while maintaining a compact Class J form factor.
The DFJ-175 is UL Listed, CSA Certified, and CE Marked RoHS compliant. These certifications support regulatory compliance in North America and Europe, facilitate manufacturer auditing and supplier qualification, and help ensure traceability during quality assurance and field inspections across global installations.
Common applications include protection for motor drives, power distribution panels, and control circuits in automation systems. Its high interrupt rating and Class J design suit switchgear and control panels operating in 600 Vac environments, with reliable performance in mixed AC and DC circuits typical of industrial plants.
The DFJ-175 provides rapid fault interruption, reducing arc energy and downtime, which lowers maintenance and repair costs. Its compact footprint simplifies installation in crowded panels, shortening commissioning times. Combined with global certifications, it supports predictable lifecycle costs and faster time-to-value for automation projects.
