Eaton DFJ-225 High Speed Fuse - CE Marked RoHS Compliant
Part Number: DFJ-225
Quick Summary
The Eaton DFJ-225 high-speed fuse protects motor drives and control circuits in industrial automation systems. It delivers precise, fast interruption for high inrush loads, reducing the risk of collateral damage and unplanned downtime. This device is UL Listed and CSA Certified, CE marked and RoHS compliant, underscoring its reliability across global machinery environments. The Class J fuse offers robust protection in a melamine tube form factor with non-indicating operation, simplifying field replacement and fuse management. In practice, this fuse supports tighter coordination between protection devices and control logic, delivering safer, more economical drive protection while meeting stringent regulatory requirements. Designed for ease of sourcing and consistent performance across Eaton Bussmann's DFJ family.
Product Information
Extended Description
DFJ-225 Eaton: Eaton Bussmann series DFJ high speed fuse, 600 Vac or less, 450 Vdc or less, 225A, 200 kAIC at 600 Vac, 100 kAIC 450 Vdc, Non Indicating, High speed fuse, Class J, Melamine tube
Product Name
Eaton Bussmann series DFJ high speed fuse
Catalog Number
DFJ-225
UPC
051712653473
Product Length/Depth
2.13 in
Product Height
7.5 in
Product Width
2.13 in
Product Weight
1.55 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Amperage Rating
225 A
Interrupt rating
200 kAIC at 600 Vac 100 kAIC 450 Vdc
Voltage rating
600 Vac or less, 450 Vdc or less
Material
Melamine tube
Packaging type
Standard
Class
Class J
Fuse indicator
Non Indicating
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - DFJ-225
DFJ-225~DRIVE FUSE
Datasheet - FNQ-30
Feature: High-speed interruption for motor drives and control circuitry. Business Impact: Reduces arc energy, minimizes collateral damage, and lowers downtime. Application: CNC machines, conveyors, and automated lines where fast fuse action protects critical loads. Feature: Melamine tube construction with non-indicating design. Business Impact: Enhanced reliability in harsh environments and simplified maintenance scheduling. Application: Dense control panels and remote location assemblies. Feature: 225 A rating with 600 Vac (450 Vdc) limits and 200 kAIC at 600 Vac. Business Impact: Tolerates inrush and peak fault currents common in drives, reducing nuisance trips. Application: Power feeds to servo drives and variable-frequency drives. Feature: UL Listed, CSA Certified, CE RoHS compliant. Business Impact: Regulatory alignment and supplier confidence, accelerating procurement. Application: Global installations in manufacturing and process industries. Feature: Class J with standard packaging. Business Impact: Easy stocking, quick replacements, and consistent performance across the DFJ family. Application: Maintenance planning and panel rebuilds in automation environments.
Get a Quick Quote for a Eaton DFJ-225
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton DFJ-225?
Enquire Now
FAQs
Its design suits industrial motor drives, conveyors, pumps, and general control circuits. With a 225 A rating and 600 Vac maximum, the DFJ-225 protects downstream equipment during start-up and inrush, reducing nuisance trips and unplanned downtime. The non-indicating Class J fuse keeps panel clutter to a minimum, while the melamine tube provides robust thermal performance in harsh environments.
Key specs include 225 A amperage rating, 600 Vac or less voltage rating, 450 Vdc or less, and interrupt ratings of 200 kAIC at 600 Vac and 100 kAIC at 450 Vdc. It is a Class J, non-indicating fuse with a melamine tube, designed for fast interruption and dependable operation in demanding automation environments.
Yes. The DFJ-225 follows the Bussmann DFJ family design, offering consistent sizing, mounting, and electrical characteristics with other DFJ devices. This compatibility simplifies spares stocking and reduces engineering adjustments when replacing a failed fuse in drives or panels. Standard packaging and mounting footprint help streamline panel design and service operations.
DFJ-225 is UL Listed and CSA Certified, CE Marked, and RoHS compliant, ensuring safety, electrical performance, and regulatory compliance across global installations. These certifications support procurement, reduce risk for audits, and enable faster project approval in industries like automotive, packaging, and process automation. They also reassure end users about reliability and traceability.
Because the DFJ-225 is a non-indicating Class J fuse, maintenance intervals focus on panel inspection and correct replacement rather than status indicators. Its fast-acting protection reduces fault-related downtime, lowering total cost of ownership. With UL and CSA certifications, procurement is straightforward, minimizing spare part lead times and improving uptime in high-demand manufacturing lines.
