Eaton DFJ-5 High Speed Fuse - UL Listed, CSA Certified
Part Number: DFJ-5
Quick Summary
Eaton DFJ-5 high speed fuse protects sensitive electrical circuits in industrial control panels and motor drives. Engineers often struggle with nuisance trips and slow protection that disrupt uptime and productivity. It carries UL Listed and CSA Certified marks, plus CE Marked RoHS compliance, providing regulatory confidence for global deployments. This compact, fast-acting device offers reliable overcurrent protection with ferrule-end termination, enabling quicker retrofits and safer system margins. By combining strong certifications with a precise 5 A, 150 Vac/dc rating, it supports scalable protection across automation architectures while easing procurement and installation considerations for OEMs and maintenance teams alike.
Product Information
Extended Description
DFJ-5 Eaton: Eaton Bussmann series DFJ high speed fuse, 150 Vac/dc, 5A, None, High speed fuse, Ferrule end X ferrule end, Class J
Product Name
Eaton Bussmann series DFJ high speed fuse
Catalog Number
DFJ-5
UPC
051712505291
Product Length/Depth
2 in
Product Height
1 in
Product Width
1 in
Product Weight
0.097 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
UL Listed CSA Certified
Amperage Rating
5 A
Voltage rating
150 Vac/dc
Packaging type
Standard
Class
Class J
Connection
Ferrule end x ferrule end
Construction size
Other
Fuse indicator
None
Utilization category
Other
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - DFJ-5
DFJ-5~DRIVE FUSE
Datasheet - FNQ-30
Feature: 5 A current rating and 150 Vac/dc voltage rating provide targeted protection for drives and panels. Business Impact: Reduces arc fault risk and limits wire insulation damage, improving uptime and extending component life in control cabinets. Application: Suitable for machine controllers and feeder circuits in automation environments. Feature: High-speed (fast-acting) fuse operation ensures rapid fault clearing. Business Impact: Minimizes damage to power supplies and downstream devices, lowering repair costs and downtime after faults. Application: Essential in drive protection and critical control loops. Feature: Ferrule-end to ferrule-end connections support quick, secure installations. Business Impact: Simplifies retrofits and cabinet upgrades with less wiring complexity and cleaner terminations. Application: Replacements inside legacy panels or new build-outs. Feature: Class J construction with CE RoHS, UL Listed, and CSA Certified compliance. Business Impact: Enables global sourcing and regulatory peace of mind, reducing supplier risk and audit findings. Application: Suitable for multi-region manufacturing lines and highly regulated environments. Feature: Compact two-inch length and lightweight form factor (2 in, 0.097 lb). Business Impact: Saves panel space, facilitates dense layouts, and lowers shipping costs. Application: Panel assemblies in tight enclosures and compact drive panels. Feature: Availability through Eaton Bussmann series with established datasheets and catalogs. Business Impact: Streamlines design-in with reliable data, technical support, and compatibility with existing fuses. Application: System integrators and OEMs standardizing protection strategies.
Get a Quick Quote for a Eaton DFJ-5
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton DFJ-5?
Enquire Now
FAQs
DFJ-5 uses ferrule-end terminations, simplifying secure connections in standard terminal blocks. Ensure terminal ferrules match the fuse size and ampacity, and mount within the specified two-inch body length to maintain proper clearance and heat dissipation. This compatibility supports quick retrofits in existing control panels without specialized tools.
DFJ-5 is UL Listed and CSA Certified, confirming adherence to safety and performance standards. It is CE Marked and RoHS compliant, ensuring environmental and regulatory alignment across global markets. These certifications facilitate multi-region sourcing and reduce compliance-related procurement risk.
The DFJ-5 is rated for 5 A and 150 Vac/dc, with Class J construction. This combination provides fast fault clearing for small to mid-range control circuits while ensuring compatibility with typical drive and panel power supplies. It balances protection with selectivity to minimize unnecessary outages.
Best suited for industrial control panels, machine drive circuits, and feeder lines in automation systems. Its compact size and ferrule-end design ease retrofits in dense control cabinets, and its fast-acting characteristics protect power electronics, sensors, and wiring harnesses from short-circuit damage.
Expect reduced downtime from quicker fault clearance and more reliable protection for drives and controls. The UL CSA CE certifications simplify vendor qualification, while the compact form factor lowers install time and returns value through longer component life and fewer nuisance trips in busy production environments.
