Eaton DFJ-6 High Speed Fuse - Class J, UL Listed CSA
Part Number: DFJ-6
Quick Summary
The DFJ-6 high speed fuse from Eaton protects motor drives and control circuits in industrial power distribution. Engineers often struggle with nuisance trips or selecting a fuse that satisfies both AC and DC voltage limits. This device carries CE marking and RoHS compliance, plus CSA Certified and UL Listed, supporting global deployments. With a Class J bolt-on design and a Melamine tube, it fits standard Bussmann series holders, delivering reliable protection and minimizing maintenance costs.
Product Information
Extended Description
DFJ-6 Eaton: Eaton Bussmann series DFJ high speed fuse, 600 Vac or less, 450 Vdc or less, 6A, 200 kAIC at 600 Vac, 100 kAIC 450 Vdc, Non Indicating, High speed fuse, Bolt-on, Class J, Melamine tube
Product Name
Eaton Bussmann series DFJ high speed fuse
Catalog Number
DFJ-6
UPC
051712653244
Product Length/Depth
0.74 in
Product Height
2.27 in
Product Width
0.74 in
Product Weight
0.9 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
CSA Certified UL Listed
Amperage Rating
6 A
Interrupt rating
200 kAIC at 600 Vac 100 kAIC 450 Vdc
Voltage rating
600 Vac or less, 450 Vdc or less
Material
Melamine tube
Packaging type
Standard
Class
Class J
Connection
Bolt-on
Fuse indicator
Non Indicating
Bussmann series complete full line catalog no. 1007
Eaton Specification Sheet - DFJ-6
DFJ-6~DRIVE FUSE
Datasheet - FNQ-30
Feature → Business Impact → Application: The DFJ-6 employs a fast-acting high-speed fuse design, reducing fault energy and protecting downstream equipment during short circuits, which translates to higher uptime in manufacturing lines and lower repair costs for drive circuits. Application: motor drives and power control panels benefit from quick interruption and dependable protection. Feature → Business Impact → Application: Rated at 6 A with a voltage ceiling of 600 Vac or 450 Vdc, it provides precise protection for small to mid-size loads without unnecessary nuisance tripping, improving process stability in automation systems. Application: control cabinets and distribution panels in factory automation. Feature → Business Impact → Application: Interruption ratings of 200 kAIC at 600 Vac and 100 kAIC at 450 Vdc support robust short-circuit resistance, safeguarding equipment and allowing faster recovery after faults. Application: heavy equipment protection and line side protection in power rails. Feature → Business Impact → Application: Bolt-on Class J construction with a melamine tube enables straightforward installation and durable mounting, reducing service time during maintenance and ensuring compatibility with the Bussmann DFJ family. Application: retrofit projects and OEM panel builds. Feature → Business Impact → Application: Non-indicating fuse plus CE RoHS and UL CSA certifications provide clear compliance, minimizing regulatory risk while simplifying procurement across international sites. Application: multi-site manufacturing and regulated environments.
Get a Quick Quote for a Eaton DFJ-6
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton DFJ-6?
Enquire Now
FAQs
The DFJ-6 is a bolt-on, Class J high-speed fuse designed to fit standard Bussmann DFJ assemblies and compatible holders in electrical protection panels. It mounts in a compact 0.74 in width space and uses a melamine tube for robust performance. It pairs with other DFJ family devices for consistent protection across panels and drive systems.
The DFJ-6 is rated at 6 A and supports voltages up to 600 Vac or less and 450 Vdc or less. Its interrupt ratings are 200 kAIC at 600 Vac and 100 kAIC at 450 Vdc, enabling fast fault interruption to protect motor drives, transformers, and automation circuits from damaging surges.
DFJ-6 carries CE Marking and RoHS compliance, plus CSA Certified and UL Listed certifications. These approvals support global deployment, regulatory compliance in diverse regions, and safer installations in industrial environments.
The DFJ-6 is ideal for motor drives, control panels, and electrical protection schemes in industrial automation. Its Class J, bolt-on design and high interrupt capability make it well-suited for both new builds and retrofits where fast protection and reliable performance are priorities.
Installation is straightforward with a bolt-on connection and a non-indicating indicator. Use standard Bussmann DFJ mounting hardware and ensure the amperage and voltage ratings match the protected circuit. Because it’s part of the DFJ family, replacement and stocking are simplified, and certifications support ongoing regulatory compliance.
