Eaton DFJ-90 High Speed Fuse - UL Listed
Part Number: DFJ-90
Quick Summary
The Eaton DFJ-90 high speed fuse protects industrial electrical circuits in control panels and motor drives. Engineers often battle nuisance trips and unclear fault isolation when selecting fuses for mixed loads and drive systems. This device carries UL Listed and CSA Certified marks with CE RoHS compliance, delivering dependable protection across North American and European installations. Its Class J clip-lock design with a melamine tube supports quick installation and robust performance in compact enclosures. With a 90 A rating and fast clearing, it helps reduce downtime while meeting strict safety and compliance requirements in industrial power distribution. This makes it suitable for motor control centers, CNC machines, and packaging lines.
Product Information
Extended Description
DFJ-90 Eaton: Eaton Bussmann series DFJ high speed fuse, 600 Vac or less, 450 Vdc or less, 90A, 200 kAIC at 600 Vac, 100 kAIC 450 Vdc, Non Indicating, High speed fuse, Clip-lock, Class J, Melamine tube - DFJ-90
Product Name
Eaton Bussmann series DFJ high speed fuse
Catalog Number
DFJ-90
UPC
051712653404
Product Length/Depth
4.83 in
Product Height
1.19 in
Product Width
1.18 in
Product Weight
0.31 lb
Warranty
Not Applicable
Compliances
CE Marked RoHS Compliant
Certifications
CSA Certified UL Listed
Amperage Rating
90 A
Interrupt rating
200 kAIC at 600 Vac 100 kAIC 450 Vdc
Voltage rating
600 Vac or less, 450 Vdc or less
Material
Melamine tube
Packaging type
Standard
Class
Class J
Connection
Clip-lock
Fuse indicator
Non Indicating
Feature: 90 A amperage rating with fast clearing for rapid fault interruption. Business Impact: minimises arc energy exposure and protects downstream equipment, reducing maintenance costs. Application: suitable for motor drives and heavy control loads in industrial panels. The DFJ-90 delivers improved reliability in power distribution networks while supporting compliance with industry standards. Feature: 600 Vac or less and 450 Vdc or less voltage ratings. Business Impact: ensures safe coordination with common industrial power rails, enabling predictable protection and easier spec compliance. Application: drives, conveyors, and machinery suites operating on mixed AC/DC systems. Long-tail keywords integrated: 600 Vac fuse, DC bus protection, AC/DC load switching. Feature: 200 kAIC interrupt rating at 600 Vac; 100 kAIC at 450 Vdc. Business Impact: high fault current handling preserves equipment and reduces downtime during faults. Application: critical power paths in metalworking, packaging, and process lines. Feature: Class J, clip-lock connection, melamine tube. Business Impact: simplifies field replacement and panel mounting, cutting install time and labor costs. Application: standard chassis with clip-lock receptacles; compatible with common Class J holders. Long-tail keywords: clip-lock fuse, melamine tube fuse, Class J protection. Feature: Non-indicating fuse with compact form factor. Business Impact: minimizes maintenance visits and avoids false alarms while preserving clear visual status in flat-panel environments. Application: compact industrial enclosures and control cabinets. Industry context and practical insight: DFJ-90 aligns with best practices for high-speed protection in drives and automation systems, offering robust compliance (UL, CSA, CE) while keeping installation straightforward for panel builders and service teams.
Get a Quick Quote for a Eaton DFJ-90
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton DFJ-90?
Enquire Now
FAQs
The DFJ-90 uses a clip-lock connection designed to fit standard Class J fuse holders, enabling quick, secure installation in common control panels and enclosures without custom adapters. This reduces commissioning time and minimizes wiring errors during replacement.
The DFJ-90 is rated for 90 A with voltage up to 600 Vac (or 450 Vdc), and provides 200 kAIC interrupt capability at 600 Vac and 100 kAIC at 450 Vdc. These ratings support fast fault interruption in motor drives and other high inrush applications, protecting both equipment and personnel.
Yes. With its Class J construction, quick-install clip-lock design, and high interrupt rating, the DFJ-90 is well-suited for motor control centers, packaging lines, CNC machines, and other automation equipment requiring reliable overcurrent protection.
DFJ-90 carries UL Listed and CSA Certified marks and CE RoHS compliance, ensuring conformity to North American and European safety and environmental standards for industrial equipment.
Because the DFJ-90 is non-indicating, visual fault status requires panel indicators or monitoring. Replace with the same model and ratings, inspect wiring for heat and arcing damage, and verify secure clip-lock seating to maintain protection integrity.
