Eaton DH225FGKV Heavy Duty Fusible Safety Switch - UL
Part Number: DH225FGKV
Quick Summary
Eaton heavy duty fusible safety switch DH225FGKV delivers safe, reliable isolation for large machinery and industrial power circuits. Operators often confront downtime and safety risks when isolation devices fail to meet code or withstand harsh environments. This unit carries UL Listed protection, a NEMA 4 enclosure, and NEC 230.62 barrier compliance, ensuring resilient performance in challenging plants while protecting personnel and equipment. For maintenance teams and OEMs, the rugged enclosure and heavy duty design translate to fewer field service calls, faster replacement, and consistent protection across shifts. By prioritizing compliance and durability, it supports uptime, safer operations, and a lower total cost of ownership in electrical protection and circuit control applications.
Product Information
Extended Description
DH225FGKV Eaton: Eaton Enhanced visible blade single-throw safety switch, Enhanced visible blade, 400 A, NEMA 4, Two-pole, Two-wire, 240 V, Max Hp: 50, 125, 50 hp (3PH @ Std fuse/time delay/250 Vdc), (2)#1/0-(2)300 kcmil or (1)#1/0-(1)750 kcmil Cu/Al
Product Name
Eaton heavy duty fusible safety switch
Catalog Number
DH225FGKV
UPC
786685972916
Product Length/Depth
65.5 in
Product Height
10.5 in
Product Width
25.5 in
Product Weight
120 lb
Compliances
NEC 230.62 (C) Compliant Barrier
Certifications
UL Listed
Catalog Notes
Heavy Duty Safety Switch (HDSS)
Enclosure
NEMA 4
Enclosure material
Painted steel
Fuse class provision
Class H
Fuse configuration
Fusible without neutral
Number Of Poles
Two-pole
Number of wires
2
Type
Heavy duty fusible safety switch
Amperage Rating
400A
HP rating - max
50, 125, 50 hp (3PH @ Std fuse/time delay/250 Vdc)
NEMA rating
NEMA 1
Voltage rating
240V
The 400 A amperage rating enables direct disconnection for large motor loads in manufacturing lines, reducing wear on upstream contactors and simplifying panel design. This translates to higher equipment uptime and lower maintenance costs. The unit is a two-pole, 240 V disconnect suitable for heavy machinery and process lines, making it a drop-in upgrade for existing HDSS installations. Fuse class provision with Class H fuses and fusible without neutral reduces arc flash risk and improves fault isolation, delivering safer start-ups and easier fuse replacement in field service while maintaining compliance with industry standards. NEMA 4 painted steel enclosure protects internal components from dust, moisture, and corrosion in plant environments; paired with UL Listed certification, it supports exterior mounting and outdoor applications. Max HP ratings of 50, 125, and 50 hp (3PH with standard fuse/time-delay/250 Vdc) enable compatibility with a wide range of motors and drives. The wiring accommodates large conductor sizes (Cu/Al) such as up to (2)300 kcmil or (1)750 kcmil, easing installation and future upgrades. The NEC 230.62 barrier compliance and rugged HDSS design provide improved safety and regulatory alignment, reducing lifecycle costs through fewer replacements and more predictable protection in mission-critical schemes.
