Eaton DH323NDKW Fusible Safety Switch - UL Listed
Part Number: DH323NDKW
Quick Summary
Eaton DH323NDKW heavy-duty fusible safety switch is designed to provide reliable isolation for industrial control panels and motor feeders. Engineers often grapple with downtime caused by complex safety devices and mis-wiring; this unit simplifies installation, reduces fault risk, and speeds maintenance. It carries UL Listed certification, uses a rugged NEMA 12/3R enclosure, and employs Class H fusing for selective protection. For project teams focusing on safety and uptime, it supports easy integration into low voltage control schemes and motor circuits while delivering robust protection and long-term value.
Product Information
Extended Description
DH323NDKW Eaton: Eaton Enhanced visible blade single-throw safety switch, Enhanced visible blade, 100 A, NEMA 12/3R, Painted galvanized steel, Class H, Neutral, Three-pole, Four-wire, 240 V, Max Hp: 7.5, 15/ 30 hp (1,3PH @Std/3PH @TD), #14-#1/0 Cu/Al
Product Name
Eaton heavy duty fusible safety switch
Catalog Number
DH323NDKW
UPC
782114022658
Product Length/Depth
27 in
Product Height
12 in
Product Width
15 in
Product Weight
30 lb
Warranty
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
Certifications
UL Listed
Catalog Notes
For 2-pole applications; use outside poles of 3-pole switch. Can be field modified to meetNEMA 3R rainproof requirements when a factory provided drain hole is opened.
Enclosure
NEMA 12, NEMA 3R
Enclosure material
Painted galvanized steel
Fuse class provision
Class H
Fuse configuration
Fusible with neutral
Number Of Poles
Three-pole
Number of wires
4
Type
Heavy duty fusible safety switch
Wire size
#14-1/0 AWG Cu/Al
Amperage Rating
100A
HP rating - max
15, 30/ 20 hp (3PH @Std, TD/250 Vdc)
NEMA rating
NEMA 12/3R
Voltage rating
240V
Product Category
Heavy Duty, Fusible with neutral
Commercial Distribution, Switching Devices, Volume 2, Tab 1
Eaton Specification Sheet - DH323NDKW
Selling Policy 25-000 - Distribution and Control Products and Services
Enclosure and environmental protection matter in harsh facilities. The NEMA 12, NEMA 3R painted galvanized steel enclosure provides dust and moisture resistance, with field modification capability to meet NEMA 3R rainproof requirements when drain holes are opened, enabling outdoor-ready installations. This translates to real business value: less enclosure swapping, fewer weather-related failures, and faster commissioning for industrial power distribution and control systems. The Class H fuse provision and fusible-with-neutral configuration support selective coordination, helping protect critical equipment while reducing nuisance fuse trips in complex motor and control circuits. With three poles and four wires, the switch ensures proper neutral handling and safe grounding for motor starters and control panels, improving reliability and simplifying wiring diagrams for maintenance teams. Rated at 100A and 240V, the unit accommodates common motor loads and control applications with predictable performance, while the #14-1/0 AWG Cu/Al wiring range offers flexibility for field terminations. The UL Listed certification reinforces compliance with safety standards, aiding audits and reducing procurement risk for industrial projects. The protective package is completed by a CS-approved warranty and Eaton’s support ecosystem, which minimizes downtime and extends life-cycle planning for critical facilities. For two-pole configurations, field adjustments using outside poles on a three-pole switch enable adaptable setups without separate hardware, streamlining install workflows and reducing stock needs.
