Eaton DH324FGKV Heavy Duty Fusible Safety Switch - UL Listed
Part Number: DH324FGKV
Quick Summary
Eaton heavy-duty fusible safety switch reliably disconnects three-phase loads in industrial panels for safer, more controlled starts. Sizing, wiring, and compliance headaches slow lines and drive downtime. The unit ships with UL Listed certification, a NEMA 1 painted-steel enclosure, and NEC 230.62 compliant barrier for safer, code-conforming installations. With a 200 A rating at 240 V and Class H fuse provision, it supports robust motor control while simplifying maintenance, retrofit projects, and future upgrades. Its three-pole design and wide conductor range—from #6 to 250 kcmil Cu/Al—plus a 30 in depth, streamline installation in compact electrical rooms. In short, you gain reliable protection, faster commissioning, and a clearer path to future scalability.
Product Information
Extended Description
DH324FGKV Eaton: Eaton Heavy duty single-throw fused safety switch, Enhanced visible blade, 200 A, NEMA 1, Painted steel, Class H, Three-pole, Three-wire, 240 V, Max Hp: 15, 25/ 15, 60/ 40 hp (1,3PH @Std/TD/250 Vdc), #6-250 kcmil Cu/Al
Product Name
Eaton heavy duty fusible safety switch
Catalog Number
DH324FGKV
UPC
786685972275
Product Length/Depth
30 in
Product Height
9.5 in
Product Width
18 in
Product Weight
37 lb
Compliances
NEC 230.62 (C) Compliant Barrier
Certifications
UL Listed
Catalog Notes
Heavy Duty Safety Switch (HDSS)
Enclosure
NEMA 1
Enclosure material
Painted steel
Fuse class provision
Class H
Fuse configuration
Fusible without neutral
Number Of Poles
Three-pole
Number of wires
3
Type
Heavy duty fusible safety switch
Wire size
#6 AWG-250 kcmil Cu/Al
Amperage Rating
200A
HP rating - max
15, 25/ 15, 60/ 40 hp (1,3PH @Std/TD/250 Vdc)
NEMA rating
NEMA 1
Voltage rating
240V
Feature: 200 A amperage rating at 240 V with three-pole configuration and fusible without neutral. Business Impact: Enables control of demanding motor loads while maintaining safe disconnect capability, reducing nuisance trips and facilitating quick fault isolation. Application: Ideal for indoor motor control panels in manufacturing lines and material handling systems. Feature: Class H fuse provision and fusible configuration. Business Impact: Provides selective, coordinated protection that minimizes damage during faults and simplifies fuse replacement. Application: Suitable for standard industrial drives and machine sections where quick maintenance is essential. Feature: NEMA 1 painted steel enclosure. Business Impact: Delivers indoor protection against dust and incidental contact, improving longevity and minimizing corrosion risk in controlled environments. Application: Wiring closets, switchgear rooms, and process areas with moderate exposure. Feature: Enhanced visible blade and status indicators. Business Impact: Allows operators to verify switch position at a glance, reducing startup delays and improving safety checks. Application: Routine shutdowns, lockout/tagout procedures, and audit-ready operations. Feature: Wide wire-size compatibility (#6 AWG–250 kcmil Cu/Al). Business Impact: Simplifies wiring, supports retrofit with existing conductors, and reduces crimping or splicing work. Application: Panel feeders and branch circuits in motors and conveyors. Feature: NEMA 1 enclosure dimensions and weight (30 in L, 18 in W, 9.5 in H, ~37 lb). Business Impact: Easier fit in constrained spaces and simpler handling during installation and service. Application: Compact control cabinets and machine enclosures where space is limited. Feature: Certifications and compliance (UL Listed, NEC barrier). Business Impact: Ensures industry-standard safety and regulatory alignment, accelerating approvals and reducing rework. Application: Facilities adhering to electrical codes and safety programs across sectors.
